HSS Drilling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 54320 Twist drill, extra-long FUTURO

HSS DIN
α: 130º 1869
P M K N S
≤ 900 Ti-Ni
≤ 900
Type UL, HSS, DIN 1869.
Application
Standard drill for general purpose use in materials up to about 1000 N/mm2.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154320.0050 2 85 125 154320.1150 4.2 120 175 154320.2250 6.4 150 215 154320.3350 8.7 175 250
154320.0100 2.1 85 125 154320.1200 4.3 125 185 154320.2300 6.5 150 215 154320.3400 8.8 175 250
154320.0150 2.2 90 135 154320.1250 4.4 125 185 154320.2350 6.6 150 215 154320.3450 9 175 250
154320.0200 2.3 90 135 154320.1300 4.5 125 185 154320.2400 6.7 150 215 154320.3500 9.2 175 250
154320.0250 2.4 95 140 154320.1350 4.6 125 185 154320.2450 6.8 155 225 154320.3550 9.3 175 250
154320.0300 2.5 95 140 154320.1400 4.7 125 185 154320.2500 6.9 155 225 154320.3600 9.5 175 250
154320.0350 2.6 95 140 154320.1450 4.8 135 195 154320.2550 7 155 225 154320.3650 9.6 185 265
154320.0400 2.7 100 150 154320.1500 4.9 135 195 154320.2600 7.1 155 225 154320.3700 9.7 185 265
154320.0450 2.8 100 150 154320.1550 5 135 195 154320.2650 7.3 155 225 154320.3750 9.8 185 265
154320.0500 2.9 100 150 154320.1600 5.1 135 195 154320.2700 7.4 155 225 154320.3800 9.9 185 265
154320.0550 3 100 150 154320.1650 5.2 135 195 154320.2750 7.5 155 225 154320.3850 10 185 265
154320.0600 3.1 105 155 154320.1700 5.3 135 195 154320.2800 7.6 165 240 154320.3900 10.2 185 265
154320.0650 3.2 105 155 154320.1750 5.4 140 205 154320.2850 7.7 165 240 154320.3950 10.5 185 265
154320.0700 3.3 105 155 154320.1800 5.5 140 205 154320.2900 7.8 165 240 154320.4000 11 195 280
154320.0750 3.4 115 165 154320.1850 5.6 140 205 154320.2950 7.9 165 240 154320.4050 11.5 195 280
154320.0800 3.5 115 165 154320.1900 5.7 140 205 154320.3000 8 165 240 154320.4100 11.8 195 280
154320.0850 3.6 115 165 154320.1950 5.8 140 205 154320.3050 8.1 165 240 154320.4150 12 205 295
154320.0900 3.7 115 165 154320.2000 5.9 140 205 154320.3100 8.2 165 240 154320.4200 12.5 205 295
154320.0950 3.8 120 175 154320.2050 6 140 205 154320.3150 8.3 165 240 154320.4250 12.7 205 295
154320.1000 3.9 120 175 154320.2100 6.1 150 215 154320.3200 8.4 165 240 154320.4300 13 205 295
154320.1050 4 120 175 154320.2150 6.2 150 215 154320.3250 8.5 165 240
154320.1100 4.1 120 175 154320.2200 6.3 150 215 154320.3300 8.6 175 250
1 54330 Twist drill, extra-long FUTURO
HSS DIN
α: 130º 1869
P M K N S
≤ 900 Ti-Ni
≤ 900
Type UL, HSS, DIN 1869.
Application
Standard drill for general purpose use in materials up to about 1000 N/mm2.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154330.0050 2 110 160 154330.0450 4.2 150 220 154330.0850 7.5 200 290 154330.1250 10.5 235 340
154330.0100 2.3 115 170 154330.0500 4.5 160 235 154330.0900 8 210 305 154330.1300 11 250 365
154330.0150 2.5 120 180 154330.0550 5 170 245 154330.0950 8.2 210 305 154330.1350 11.5 250 365
154330.0200 3 130 190 154330.0600 5.5 180 260 154330.1000 8.5 210 305 154330.1400 12 260 375
154330.0250 3.2 135 200 154330.0650 6 180 260 154330.1050 9 220 320 154330.1450 12.5 260 375
154330.0300 3.3 135 200 154330.0700 6.3 190 275 154330.1100 9.5 220 320 154330.1500 13 260 375
154330.0350 3.5 145 210 154330.0750 6.5 190 275 154330.1150 10 235 340
154330.0400 4 150 220 154330.0800 7 200 290 154330.1200 10.2 235 340
1 54340 Twist drill, extra-long FUTURO
HSS DIN
α: 130º 1869

P M K N S
≤ 900 Ti-Ni
≤ 900
Type UL, HSS, DIN 1869.
Application
Standard drill for general purpose use in materials up to about 1000 N/mm2.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154340.0050 2.5 150 225 154340.0350 5 210 315 154340.0650 7.5 250 370 154340.0950 10.5 295 430
154340.0100 3 160 240 154340.0400 5.5 225 330 154340.0700 8 265 390 154340.1000 11 310 455
154340.0150 3.5 180 265 154340.0450 6 225 330 154340.0750 8.5 265 390 154340.1050 11.5 310 455
154340.0200 4 190 280 154340.0500 6.5 235 350 154340.0800 9 280 410 154340.1100 12 330 480
154340.0250 4.2 190 280 154340.0550 6.8 250 370 154340.0850 9.5 280 410 154340.1150 12.5 330 480
154340.0300 4.5 200 295 154340.0600 7 250 370 154340.0900 10 295 430 154340.1200 13 330 480
