1 53060 Twist drill TITEX

HSS DIN
α: 130º 340
P M K N S
Ni

A1522, Type UFL, HSS, polished surface; from 1.9 mm damped; DIN 340.
Application
Twist drill with specially designed geometry for optimized chip formation and chip evacuation;
allows greater drilling depths without venting; particularly broad range of possible uses in all long-
chipping materials up to about 1000 N/mm2; also for short-chipping materials up to about 1000
N/mm2 in the case of greater drilling depths.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
153060.0100 1 33 56 153060.2600 3.5 73 112 153060.5100 6 91 139 153060.7600 8.5 109 165
153060.0200 1.1 37 60 153060.2700 3.6 73 112 153060.5200 6.1 97 148 153060.7700 8.6 115 175
153060.0300 1.2 41 65 153060.2800 3.7 73 112 153060.5300 6.2 97 148 153060.7800 8.7 115 175
153060.0400 1.3 41 65 153060.2900 3.8 78 119 153060.5400 6.3 97 148 153060.7900 8.8 115 175
153060.0500 1.4 45 70 153060.3000 3.9 78 119 153060.5500 6.4 97 148 153060.8000 8.9 115 175
153060.0600 1.5 45 70 153060.3100 4 78 119 153060.5600 6.5 97 148 153060.8100 9 115 175
153060.0700 1.6 50 76 153060.3200 4.1 78 119 153060.5700 6.6 97 148 153060.8200 9.1 115 175
153060.0800 1.7 50 76 153060.3300 4.2 78 119 153060.5800 6.7 97 148 153060.8300 9.2 115 175
153060.0900 1.8 53 80 153060.3400 4.3 82 126 153060.5900 6.8 102 156 153060.8400 9.3 115 175
153060.1000 1.9 53 80 153060.3500 4.4 82 126 153060.6000 6.9 102 156 153060.8500 9.4 115 175
153060.1100 2 56 85 153060.3600 4.5 82 126 153060.6100 7 102 156 153060.8600 9.5 115 175
153060.1200 2.1 56 85 153060.3700 4.6 82 126 153060.6200 7.1 102 156 153060.8700 9.6 121 184
153060.1300 2.2 59 90 153060.3800 4.7 82 126 153060.6300 7.2 102 156 153060.8800 9.7 121 184
153060.1400 2.3 59 90 153060.3900 4.8 87 132 153060.6400 7.3 102 156 153060.8900 9.8 121 184
153060.1500 2.4 62 95 153060.4000 4.9 87 132 153060.6500 7.4 102 156 153060.9000 9.9 121 184
153060.1600 2.5 62 95 153060.4100 5 87 132 153060.6600 7.5 102 156 153060.9100 10 121 184
153060.1700 2.6 62 95 153060.4200 5.1 87 132 153060.6700 7.6 109 165 153060.9200 10.2 121 184
153060.1800 2.7 66 100 153060.4300 5.2 87 132 153060.6800 7.7 109 165 153060.9300 10.5 121 184
153060.1900 2.8 66 100 153060.4400 5.3 87 132 153060.6900 7.8 109 165 153060.9400 10.8 128 195
153060.2000 2.9 66 100 153060.4500 5.4 91 139 153060.7000 7.9 109 165 153060.9500 11 128 195
153060.2100 3 66 100 153060.4600 5.5 91 139 153060.7100 8 109 165 153060.9600 11.2 128 195
153060.2200 3.1 69 106 153060.4700 5.6 91 139 153060.7200 8.1 109 165 153060.9700 11.5 128 195
153060.2300 3.2 69 106 153060.4800 5.7 91 139 153060.7300 8.2 109 165 153060.9800 11.8 128 195
153060.2400 3.3 69 106 153060.4900 5.8 91 139 153060.7400 8.3 109 165 153060.9900 12 134 205
153060.2500 3.4 73 112 153060.5000 5.9 91 139 153060.7500 8.4 109 165
1 53080 Twist drill GÜHRING
HSS TiN DIN
α: 130º 340
P K N S
≤ 850 Ti

668, Type GT 100, TiN, HSS, DIN 340.
Application
Particularly stable specialty drill for drilling deep holes under difficult drilling conditions, such as
with poor chip evacuation, causing insufficient cooling of the drill tip.
Suited for drilling cast iron and steels up to max. 1000 N/mm2.
Exception: CrNi steels, stainless steels and similar materials.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
153080.0100 1 33 56 153080.1800 2.7 66 100 153080.3500 4.4 82 126 153080.5200 6.5 97 148
153080.0200 1.1 37 60 153080.1900 2.8 66 100 153080.3600 4.5 82 126 153080.5300 6.8 102 156
153080.0300 1.2 41 65 153080.2000 2.9 66 100 153080.3700 4.6 82 126 153080.5400 7 102 156
153080.0400 1.3 41 65 153080.2100 3 66 100 153080.3800 4.7 82 126 153080.5500 7.5 102 156
153080.0500 1.4 45 70 153080.2200 3.1 69 106 153080.3900 4.8 87 132 153080.5600 8 109 165
153080.0600 1.5 45 70 153080.2300 3.2 69 106 153080.4000 4.9 87 132 153080.5700 8.5 109 165
153080.0700 1.6 50 76 153080.2400 3.3 69 106 153080.4100 5 87 132 153080.5800 9 115 175
153080.0800 1.7 50 76 153080.2500 3.4 73 112 153080.4200 5.1 87 132 153080.5900 9.5 115 175
153080.0900 1.8 53 80 153080.2600 3.5 73 112 153080.4300 5.2 87 132 153080.6000 10 121 184
153080.1000 1.9 53 80 153080.2700 3.6 73 112 153080.4400 5.3 87 132 153080.6100 10.2 121 184
153080.1100 2 56 85 153080.2800 3.7 73 112 153080.4500 5.4 91 139 153080.6200 10.5 121 184
153080.1200 2.1 56 85 153080.2900 3.8 78 119 153080.4600 5.5 91 139 153080.6300 11 128 195
153080.1300 2.2 59 90 153080.3000 3.9 78 119 153080.4700 5.6 91 139 153080.6400 11.5 128 195
153080.1400 2.3 59 90 153080.3100 4 78 119 153080.4800 5.7 91 139 153080.6500 12 134 205
153080.1500 2.4 62 95 153080.3200 4.1 78 119 153080.4900 5.8 91 139
153080.1600 2.5 62 95 153080.3300 4.2 78 119 153080.5000 5.9 91 139
153080.1700 2.6 62 95 153080.3400 4.3 82 126 153080.5100 6 91 139
