HSS Drilling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
153140 Twist drill TITEX
VA
HSS-E DIN
α: 130º 340
P M N S
Cu Ti-Ni

A1544, Type VA, HSS-E, polished surface; DIN 340.
Application
Heat-resistant twist drill with specially designed geometry for use in hard-to-machine materials
that tend to be highly work-hardening, such as stainless steels, acid- and heat-resistant steels and
titanium.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
153140.0100 1 33 56 153140.1900 2.8 66 100 153140.3700 4.6 82 126 153140.5500 7.5 102 156
153140.0200 1.1 37 60 153140.2000 2.9 66 100 153140.3800 4.7 82 126 153140.5600 7.8 109 156
153140.0300 1.2 41 65 153140.2100 3 66 100 153140.3900 4.8 87 132 153140.5700 8 109 165
153140.0400 1.3 41 65 153140.2200 3.1 69 106 153140.4000 4.9 87 132 153140.5800 8.5 109 165
153140.0500 1.4 45 70 153140.2300 3.2 69 106 153140.4100 5 87 132 153140.5900 8.8 115 175
153140.0600 1.5 45 70 153140.2400 3.3 69 106 153140.4200 5.1 87 132 153140.6000 9 115 175
153140.0700 1.6 50 76 153140.2500 3.4 73 112 153140.4300 5.2 87 132 153140.6100 9.5 115 175
153140.0800 1.7 50 76 153140.2600 3.5 73 112 153140.4400 5.3 87 132 153140.6200 9.8 121 184
153140.0900 1.8 53 80 153140.2700 3.6 73 112 153140.4500 5.4 91 139 153140.6300 10 121 184
153140.1000 1.9 53 80 153140.2800 3.7 73 112 153140.4600 5.5 91 139 153140.6400 10.2 121 184
153140.1100 2 56 85 153140.2900 3.8 78 119 153140.4700 5.6 91 139 153140.6500 10.5 121 184
153140.1200 2.1 56 85 153140.3000 3.9 78 119 153140.4800 5.7 91 139 153140.6600 10.8 128 195
153140.1300 2.2 59 90 153140.3100 4 78 119 153140.4900 5.8 91 139 153140.6700 11 128 195
153140.1400 2.3 59 90 153140.3200 4.1 78 119 153140.5000 5.9 91 139 153140.6800 11.5 128 195
153140.1500 2.4 62 95 153140.3300 4.2 78 119 153140.5100 6 91 139 153140.6900 11.8 128 195
153140.1600 2.5 62 95 153140.3400 4.3 82 126 153140.5200 6.5 97 148 153140.7000 12 134 205
153140.1700 2.6 62 95 153140.3500 4.4 82 126 153140.5300 6.8 102 156
153140.1800 2.7 66 100 153140.3600 4.5 82 126 153140.5400 7 102 156

154300 Twist drill FUTURO
HSS DIN
α: 118º 340
P K N S
Ti

Type N, HSS, ground flutes; DIN 340.
Application
Standard drill for drilling deep holes and drilling through boring bushes. For drilling steel and cast
steel (alloyed and unalloyed), cast iron, malleable cast iron, ductile cast iron, sintered iron, etc.
1 pack contains: 0.5...0.9 mm: 10
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154300.0100 0.5 12 32 154300.2300 2.7 66 100 154300.4500 4.9 87 132 154300.6700 9.8 121 184
154300.0200 0.6 15 35 154300.2400 2.8 66 100 154300.4600 5 87 132 154300.6800 10 121 184
154300.0300 0.7 21 42 154300.2500 2.9 66 100 154300.4700 5.1 87 132 154300.6900 10.2 121 184
154300.0400 0.8 25 46 154300.2600 3 66 100 154300.4800 5.2 87 132 154300.7000 10.5 121 184
154300.0500 0.9 29 51 154300.2700 3.1 69 106 154300.4900 5.3 87 132 154300.7100 11 128 195
154300.0600 1 33 56 154300.2800 3.2 69 106 154300.5000 5.4 91 139 154300.7200 11.5 128 195
154300.0700 1.1 37 60 154300.2900 3.3 69 106 154300.5100 5.5 91 139 154300.7300 11.8 128 195
154300.0800 1.2 41 65 154300.3000 3.4 73 112 154300.5200 5.6 91 139 154300.7400 12 134 205
154300.0900 1.3 41 65 154300.3100 3.5 73 112 154300.5300 5.7 91 139 154300.7500 12.5 134 205
154300.1000 1.4 45 70 154300.3200 3.6 73 112 154300.5400 5.8 91 139 154300.7600 13 134 205
154300.1100 1.5 45 70 154300.3300 3.7 73 112 154300.5500 5.9 91 139 154300.7700 13.5 140 214
154300.1200 1.6 50 76 154300.3400 3.8 78 119 154300.5600 6 91 139 154300.7800 14 140 214
154300.1300 1.7 50 76 154300.3500 3.9 78 119 154300.5700 6.5 97 148 154300.7900 15 144 220
154300.1400 1.8 53 80 154300.3600 4 78 119 154300.5800 6.8 102 156 154300.8000 16 149 227
154300.1500 1.9 53 80 154300.3700 4.1 78 119 154300.5900 7 102 156 154300.8100 16.5 154 235
154300.1600 2 56 85 154300.3800 4.2 78 119 154300.6000 7.5 102 156 154300.8200 17 154 235
154300.1700 2.1 56 85 154300.3900 4.3 82 126 154300.6100 7.8 109 165 154300.8300 17.5 158 241
154300.1800 2.2 59 90 154300.4000 4.4 82 126 154300.6200 8 109 165 154300.8400 18 158 241
154300.1900 2.3 59 90 154300.4100 4.5 82 126 154300.6300 8.5 109 165 154300.8500 18.5 162 247
154300.2000 2.4 62 95 154300.4200 4.6 82 126 154300.6400 8.8 115 175 154300.8600 19 162 247
154300.2100 2.5 62 95 154300.4300 4.7 82 126 154300.6500 9 115 175 154300.8700 19.5 166 254
154300.2200 2.6 62 95 154300.4400 4.8 87 132 154300.6600 9.5 115 175 154300.8800 20 166 254
