HSS Drilling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
154310 Twist drill FUTURO

HSS TiN DIN
α: 118º 340
P K N S
Ti

Type N, HSS, TiN-coating, ground flutes, DIN 340.
Application
Standard drill for drilling deep holes and drilling through boring bushes. For drilling steel and cast
steel (alloyed and unalloyed), cast iron, malleable cast iron, ductile cast iron, sintered iron.
1 pack contains: 0.5...0.9 mm: 10
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154310.0100 0.5 12 32 154310.2200 2.6 62 95 154310.4300 4.7 82 126 154310.6400 8.8 115 175
154310.0200 0.6 15 35 154310.2300 2.7 66 100 154310.4400 4.8 87 132 154310.6500 9 115 175
154310.0300 0.7 21 42 154310.2400 2.8 66 100 154310.4500 4.9 87 132 154310.6600 9.5 115 175
154310.0400 0.8 25 46 154310.2500 2.9 66 100 154310.4600 5 87 132 154310.6700 9.8 121 184
154310.0500 0.9 29 51 154310.2600 3 66 100 154310.4700 5.1 87 132 154310.6800 10 121 184
154310.0600 1 33 56 154310.2700 3.1 69 106 154310.4800 5.2 87 132 154310.6900 10.2 121 184
154310.0700 1.1 37 60 154310.2800 3.2 69 106 154310.4900 5.3 87 132 154310.7000 10.5 121 184
154310.0800 1.2 41 65 154310.2900 3.3 69 106 154310.5000 5.4 91 139 154310.7100 11 128 195
154310.0900 1.3 41 65 154310.3000 3.4 73 112 154310.5100 5.5 91 139 154310.7200 11.5 128 195
154310.1000 1.4 45 70 154310.3100 3.5 73 112 154310.5200 5.6 91 139 154310.7300 11.8 128 195
154310.1100 1.5 45 70 154310.3200 3.6 73 112 154310.5300 5.7 91 139 154310.7400 12 134 205
154310.1200 1.6 50 76 154310.3300 3.7 73 112 154310.5400 5.8 91 139 154310.7500 12.5 134 205
154310.1300 1.7 50 76 154310.3400 3.8 78 119 154310.5500 5.9 91 139 154310.7600 13 134 205
154310.1400 1.8 53 80 154310.3500 3.9 78 119 154310.5600 6 91 139 154310.7700 13.5 140 214
154310.1500 1.9 53 80 154310.3600 4 78 119 154310.5700 6.5 97 148 154310.7800 14 140 214
154310.1600 2 56 85 154310.3700 4.1 78 119 154310.5800 6.8 102 156 154310.7900 14.5 144 220
154310.1700 2.1 56 85 154310.3800 4.2 78 119 154310.5900 7 102 156 154310.8000 15 144 220
154310.1800 2.2 59 90 154310.3900 4.3 82 126 154310.6000 7.5 102 156 154310.8100 15.5 149 227
154310.1900 2.3 59 90 154310.4000 4.4 82 126 154310.6100 7.8 109 165 154310.8200 16 149 227
154310.2000 2.4 62 95 154310.4100 4.5 82 126 154310.6200 8 109 165
154310.2100 2.5 62 95 154310.4200 4.6 82 126 154310.6300 8.5 109 165
153205 Deep hole drill GÜHRING
HSS DIN
α: 118º 1869/1
P M K N
≤ 900

235, Type N, HSS, DIN 1869-1.
Application
Standard drill for general purpose use in materials up to about 1000 N/mm2.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
153205.0100 2 85 125 153205.1800 3.7 115 165 153205.3600 5.4 140 205 153205.5400 7.2 155 225
153205.0200 2.1 85 125 153205.1900 3.8 120 175 153205.3700 5.5 140 205 153205.5600 7.4 155 225
153205.0300 2.2 90 135 153205.2000 3.9 120 175 153205.3800 5.6 140 205 153205.5700 7.5 155 225
153205.0400 2.3 90 135 153205.2100 4 120 175 153205.3900 5.7 140 205 153205.5800 7.6 165 240
153205.0500 2.4 95 140 153205.2200 4.1 120 175 153205.4000 5.8 140 205 153205.5900 7.7 165 240
153205.0600 2.5 95 140 153205.2300 4.2 120 175 153205.4100 5.9 140 205 153205.6000 7.8 165 240
153205.0700 2.6 95 140 153205.2500 4.3 125 185 153205.4200 6 140 205 153205.6100 7.9 165 240
153205.0800 2.7 100 150 153205.2600 4.4 125 185 153205.4300 6.1 150 215 153205.6200 8 165 240
153205.0900 2.8 100 150 153205.2700 4.5 125 185 153205.4400 6.2 150 215 153205.6300 8.1 165 240
153205.1000 2.9 100 150 153205.2800 4.6 125 185 153205.4500 6.3 150 215 153205.6400 8.2 165 240
153205.1100 3 100 150 153205.2900 4.7 125 185 153205.4600 6.4 150 215 153205.6600 8.5 165 240
153205.1200 3.1 105 155 153205.3000 4.8 135 195 153205.4700 6.5 150 215 153205.6700 8.8 175 250
153205.1300 3.2 105 155 153205.3100 4.9 135 195 153205.4800 6.6 150 215 153205.6800 9 175 250
153205.1400 3.3 105 155 153205.3200 5 135 195 153205.4900 6.7 150 215 153205.7000 9.5 175 250
153205.1500 3.4 115 165 153205.3300 5.1 135 195 153205.5000 6.8 155 225 153205.7100 9.8 185 265
153205.1600 3.5 115 165 153205.3400 5.2 135 195 153205.5200 7 155 225 153205.7200 10 185 265
153205.1700 3.6 115 165 153205.3500 5.3 135 195 153205.5300 7.1 155 225

648 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
