Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
139150 Face milling cutter 45° FUTURO Hexagon

Face milling cutter 45° hexagon, nickel-plated with internal cooling, 12 effective cutting edges
with double-sided and postive indexable inserts. Suitable for cutting depths up to 4.5 mm.
Indexable inserts: 139160
Spare parts: 139300
Package content: Screwdriver not included.
Order ID D H d Z ap Turning plate
mm mm mm mm
139150.0100 40 40 16 4 4.5 HOKU08...
139150.0200 50 40 22 4 4.5 HOKU08...
139150.0300 63 40 22 5 4.5 HOKU08...
139150.0400 80 50 27 6 4.5 HOKU08...

139160 Indexable insert FUTURO
P M K S

For 139150.
Types
• K15C: for cast iron.
• PK25C: for steel and cast iron.
• MS35C: for stainless steel and superalloys.
• P35P: for steel.
• K15C: for cast iron.
• M35P: for stainless steel.
Order ID Code Type l s ap
mm mm mm
139160.0100 HOKU 0806 MM K15C 14.7 5.3 4.5
139160.0200 HOKU 0806 MM PK25C 14.7 5.3 4.5
139160.0300 HOKU 0806 MM MS35C 14.7 5.3 4.5
139160.0400 HOKU 0806 MM P35P 14.7 5.3 4.5
139160.0500 HOKU 0806 MM K15C 14.7 5.3 4.5
139160.0600 HOKU 0806 MM M35P 14.7 5.3 4.5
139200 Face milling cutter 45° FUTURO

Unequally divided face milling cutter 45° nickel-plated with internal cooling, 6 effective cutting
edges and positive indexable inserts. Suitable for cutting depths up to 4.5 mm.
Indexable inserts: 139210
Spare parts: 139300
Package content: Screwdriver not included.
Order ID D Da H d Z ap Turning plate
mm mm mm mm mm
139200.0100 40 52.2 40 16 4 4.5 HPKT06..
139200.0200 50 62.2 40 22 5 4.5 HPKT06..
139200.0300 63 75.2 40 22 6 4.5 HPKT06..
139200.0400 80 92.2 50 27 7 4.5 HPKT06..
139200.0500 100 112.2 50 32 9 4.5 HPKT06..
