Milling with changeable milling head Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
131160 Cutting head SECO Minimaster

VHM TiN Z
3
P M K N S
Cu, AI Ti-Ni

Corner and groove cutter, 3 cutting edges
• F30M: Basic type with internal cooling for milling stainless steel, hardened steel and superal-
loys.
• F40M: PVD-coated type with internal cooling for finishing and first-cutting all materials, in-
cluding superalloys. Outstanding when there is a tendency to vibrate and when coolant is used.
Spare parts: 131300
Note: Key has to be ordered seperately 131300.
Order ID Code D r l l3 Type Spanners
mm mm mm mm
131160.0030 MM06-06007-A30-E02 6 - 7.5 9.9 F30M MM0416
131160.0060 MM06-06007-R05A30-M02 6 0.5 7.5 9.9 F40M MM0416
131160.0090 MM06-06007-R10A30-M02 6 1 7.5 9.9 F40M MM0416
131160.0100 MM08-08009-A30-E03 8 - 10 13 F30M MM0416
131160.0200 MM08-08009-R05A30-M03 8 0.5 10 13 F40M MM0416
131160.0300 MM08-08009-R10A30-D03 8 0.5 10 13 F30M MM0416
131160.0400 MM10-10012-A30-E03 10 - 11.8 15.7 F30M MM0416
131160.0500 MM10-10012-R05A30-M03 10 0.5 11.8 15.7 F40M MM0416
131160.0600 MM10-10012-R10A30-D03 10 1 11.8 15.7 F30M MM0416
131160.0700 MM12-12015-A30-E04 12 - 15.5 19.9 F30M MM0416
131160.0800 MM12-12015-R05A30-M04 12 0.5 15.5 19.9 F40M MM0416
131160.0900 MM12-12015-R10A30-E04 12 1 15.5 19.9 F30M MM0416
131160.1000 MM16-16019-A30-E06 16 - 19.2 24.5 F30M MM0416
131160.1100 MM16-16019-R05A30-M06 16 0.5 19.2 24.5 F40M MM0416
131160.1200 MM16-16019-R10A30-E06 16 1 19.2 24.5 F30M MM0416
131200 Cutting head SECO Minimaster
VHM TiN Z
2

P M K N S
Cu, AI Ti-Ni

Copy milling
• F30M: Basic type for stainless steel, hardened steel and superalloys.
Spare parts: 131300
Note: Key must be ordered separately 131300.
Order ID Code D r l l3 Spanners
mm mm mm mm
131200.0050 MM06-06006-B90-MD02 6 3 6.14 7 MM0612
131200.0100 MM08-08008-B90-MD03 8 4 8.1 9.4 MM0612
131200.0200 MM10-10010-B90-MD04 10 5 10.2 11.8 MM0612
131200.0300 MM12-12012-B90-MD05 12 6 12.3 14.1 MM0612
131200.0400 MM16-16016-B90-MD07 16 8 16.2 18.4 MM1420
