Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
132440 High-feed end mill WALTER
F2330

High-performance end mill for high-speed machining of a wide range of materials.
Extremely high feed rates can be achieved with this tool (Fz max = 3mm).
Indexable inserts: 132470
Spare parts: 138040
Order ID Da Dc d1 X2 X1 Z
mm mm mm mm mm
132440.0100 20 10 20 200 30 2
132440.0200 25 15 25 200 35 3
132440.0300 32 18 32 250 40 3
Order ID ap ae Turning plates
mm mm
132440.0100 1 7 P 2633. - R10
132440.0200 1 7 P 2633. - R10
132440.0300 1.5 10 P 2633. - R14
132450 High-feed end mill WALTER
F2330
High-performance end mill for high-speed machining of a wide range of materials.
Extremely high feed rates can be achieved with this tool (Fz max = 3.5 mm).
Indexable inserts: 132470 (P 2633. - R 14)
Spare parts: 138040
Order ID Da Dc d1 X1 Z ap ae
mm mm mm mm mm mm
132450.0100 52 38 22 40 5 1.5 10
132450.0200 66 52 27 50 6 1.5 10
132450.0300 85 71 27 50 7 1.5 10

132470 Indexable insert WALTER

P M K S

For 132440, 132450
Types
• WKP 35: for steel and cast iron.
Order ID Code Type s r d ap
mm mm mm mm
132470.0100 P 26335 - R10 WKP35 3.18 0.8 6.75 1

570 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
