Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
132520 Indexable insert COROMANT
CoroMill Century 590
N

For 132500
Geometries
• NL: Aluminium, finish machining
• NW: Aluminium, wiper geometry (excellent surface)
Types
• H10: Uncoated, fine grained; outstanding cutting edge sharpness; for Al.
Order ID Code Type l r iW bs ap max.
mm mm mm mm mm
132520.0100 R590-110504H-NL H10 11 0.4 11.5 2.2 10
132520.0200 R590-110504H-NW H10 11 0.4 11.5 7.2 2

139100 Face milling cutter 45° FUTURO

Face mill 45° nickel-plated with internal cooling and 8 effective cutting edges and rectangular,
double-sided, positive indexable inserts.
Application
Face milling and roughing
Indexable inserts: 139110
Spare parts: 139300
Package content: Screwdriver not included.
Order ID D Da H d Z ap Turning plate
mm mm mm mm mm
139100.0100 40 55 45 16 4 6.5 SOKU15...
139100.0200 50 65 45 22 4 6.5 SOKU15...
139100.0300 63 78 45 22 5 6.5 SOKU15...
139100.0400 80 95 50 27 6 6.5 SOKU15...
139100.0500 100 115 50 32 7 6.5 SOKU15...
139100.0600 125 140 63 40 8 6.5 SOKU15...
139110 Indexable insert FUTURO
P M K S

For 139100.
Types
• K15C: for cast iron.
• PK25C: for steel and cast iron.
• MS35C: for stainless steel and superalloys.
• P35P: for steel.
• M35P: four stainless steel.
Order ID Code Type l l1 r s ap
mm mm mm mm mm
139110.0100 SOKU 1505 MM K15C 15.875 3.65 1 6.03 6.5
139110.0200 SOKU 1505 MM PK25C 15.875 3.65 1 6.03 6.5
139110.0300 SOKU 1505 MM MS35C 15.875 3.65 1 6.03 6.5
139110.0400 SOKU 1505 MM P35P 15.875 3.65 1 6.03 6.5
139110.0500 SOKU 1505 MM M35P 15.875 3.65 1 6.03 6.5
