Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
140040 Cutting insert FUTURO
SEKT
P M K S

For 140000
Types
• UNI: micro-grain; universal insert for improved performance and longer service life.
Order ID Code Type l s Alpha ap
mm mm mm
140040.0100 SEKT 1204 AFTN UNI 12 4.76 20° 6

132100 Face milling cutters 45° WALTER NOVEX Mini KW
F2233
Face cutter system for complete machining of all steel, cast iron and aluminium materials. With
a basic body combined with the various geometries and types, this is a universal cutting system
featuring very smooth running and an economical, 4-edge indexable insert.
Especially suitable for low-power machines (SK30) and stable machines up to a cutting depth of
5 mm.
Indexable inserts: 132120
Spare parts: 138040
Order ID Dc d1 X1 Z Lc ap
mm mm mm mm mm
132100.0100 32 16 40 4 5 5
132100.0200 40 22 40 4 5 5
132100.0300 50 22 40 5 5 5
132100.0400 63 22 40 5 5 5

132120 Indexable insert WALTER SD..09T3
P M K N

For 132100 D57 F57
Geometries
• F57: Ground cutting insert with chip basin for outstanding surface quality.
• G88: Highly positive geometry for machining aluminium.
Types
• WXM 35: for stainless steel
• WK 10: Uncoated, wear-resistant fine-grained, for finish machining of aluminium alloys
Order ID Code Type l s r b ap G88
mm mm mm mm mm
132120.0600 SDGT 09 T3 AEN-F57 WXM35 9.52 3.97 0.5 1.2 5
132120.0700 SDGT 09 T3 AEN-G88 WK10 9.52 3.97 0.5 1.2 5
