Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
132310 Indexable inserts SECO SEEX/SEMX

P M S

For 132305
Geometries
• M10: moderately hard machining at moderate chip thicknesses
• ME11: easy and moderately hard machining at moderate chip thicknesses
• M15: moderately hard machining at larger chip thicknesses
Types
• F40M: for all materials, incl. superalloys, pre-finishing, finish-machining at low feed rates and/or
low cutting speeds, with/without cooling
• MP2500: basic grade for steel and easy to moderately hard-to-machine stainless steel, with/
without cooling
• T350M: basic grade for hard-to-machine steel, an alternative for difficult milling tasks in steel
Order ID Code Type l s B ap
mm mm mm mm
132310.0100 SEEX 1204AFN-M10 F40M 12.7 4.76 1.57 6
132310.0200 SEEX 1204AFTN-ME11 MP2500 12.7 4.76 1.57 6
132310.0300 SEMX 1204AFTN-M15 T350M 12.7 4.76 1.57 6

139000 High-feed end mill FUTURO

High-feed end mill, nickel-plated with internal cooling for maximum stock removal rates Desig-
ned for high stability, therefore reduced vibration, minimum power consumption and soft cutting.
Appropriate accessories:
139010 Indexable insert FUTURO, 325270 TORX screwdriver FUTURO
®
Corresponding inserts:
139010 Indexable insert FUTURO
Package content: Screwdriver not included.
Order ID D H d Z ap Turning plate
mm mm mm mm
139000.0100 50 40 22 4 2 XOLT
139000.0150 52 40 22 5 2 XOLT
139000.0200 63 40 22 5 2 XOLT
139000.0300 80 50 27 7 2 XOLT

139010 Indexable insert FUTURO
P M S

For 139000.
Types
• PK35P: for steel.
• MS35C: for stainless steel and superalloys.
Order ID Code Type l r s Alpha ap
mm mm mm mm
139010.0100 XOLT 130410 MR PK35P 13 1 4.76 9 ° 2
139010.0200 XOLT 130410 MR MS35C 13 1 4.76 9 ° 2

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 569
