Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
127240 Solid carbide economy end mill FUTURO

VHM TiAIN λ: 30º Z
γ: 9º 3
P M K N S
Cu, AI Ni
≤ 900
Type N, TiAlN, sizes 2 mm and greater with Weldon flat, angle of twist 30°, centre cut, works
standard, extra short.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127240.0100 0.5 1.5 3 38 127240.1600 5.75 8 6 39
127240.0200 0.6 1.5 3 38 127240.1700 6 8 6 39
127240.0300 0.8 2 3 38 127240.1800 6.75 10 8 42
127240.0400 1 2 3 38 127240.1900 7 10 8 42
127240.0500 1.2 2 3 38 127240.2000 7.75 10 8 42
127240.0600 1.5 2 3 38 127240.2100 8 11 8 43
127240.0700 1.8 2 3 38 127240.2200 8.7 11 10 48
127240.0800 2 4 6 35 127240.2300 9 11 10 48
127240.0900 2.5 5 6 36 127240.2400 9.7 11 10 48
127240.1000 3 5 6 36 127240.2500 10 13 10 50
127240.1100 3.5 6 6 37 127240.2600 12 15 12 55
127240.1200 4 7 6 38 127240.2700 14 15 14 58
127240.1300 4.5 8 6 38 127240.2800 16 18 16 62
127240.1400 5 8 6 39 127240.2900 18 20 18 70
127240.1500 5.5 8 6 39 127240.3000 20 22 20 75
127340 Solid carbide slot cutter FUTURO
VHM TiAIN λ: 30º Z
γ: 8º 2
P M K N S
Cu, AI Ni
≤ 900
Type N, TiAlN, with Weldon flat, angle of twist 30°, centre cut, DIN 6527, short.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127340.0200 3 4 6 50 127340.0700 6 7 6 54
127340.0300 3.5 4 6 50 127340.0900 8 9 8 58
127340.0400 4 5 6 54 127340.1000 9 10 10 66
127340.0500 4.5 5 6 54 127340.1100 10 11 10 66
127340.0600 5 6 6 54
127360 Solid carbide slot cutter FUTURO
VHM λ: 30º Z
γ: 12º 2

P M K N
≤ 900 Cu, AI

Type N, sizes 3 mm and greater with Weldon flat, angle of twist 30°, centre cut, DIN 6527, short.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127360.0100 2 6 3 38 127360.1200 7.75 16 8 63
127360.0200 3 7 6 57 127360.1300 8 16 8 63
127360.0400 3.8 8 6 57 127360.1600 10 19 10 72
127360.0500 4 8 6 57 127360.1800 12 22 12 83
127360.0800 5 10 6 57 127360.1900 14 22 14 83
127360.0900 5.75 10 6 57 127360.2000 16 26 16 92
127360.1000 6 10 6 57 127360.2100 18 26 18 92
127360.1100 7 13 8 63 127360.2200 20 32 20 104

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 525
