Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 27540 Solid carbide power end mill FUTURO

VHM TiAIN λ: 30º Z
γ: 3º 3-4
P M S
Ti-Ni

Type NRF, roughing profile, TiAlN, with Weldon flat, angle of twist 30°, works standard.
Application
Especially well suited to machining stainless steel, titanium, Inconel.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Z Order ID d1 l2 d2 l1 Z
mm mm mm mm mm mm mm mm
127540.0100 6 16 6 57 3 127540.0600 12 26 12 83 4
127540.0200 7 16 8 63 3 127540.0700 14 26 14 83 4
127540.0300 8 16 8 63 3 127540.0800 16 32 16 92 4
127540.0400 9 19 10 72 4 127540.0900 18 32 18 92 4
127540.0500 10 22 10 72 4 127540.1000 20 38 20 104 4
1 27550 Solid carbide roughing end mill FUTURO
VHM TiAIN λ: 25º Z
4

P M K N S
Cu Ni
≤ 900
Type NRF, TiAlN, with internal cooling, with Weldon flat, angle of twist 25°, long, works stan-
dard.
Application:
Universally applicable in steel, Inox, and cast materials up to 45 HRc.
Tolerance d2: h6
Order ID d1 l2 l1 d2 Order ID d1 l2 l1 d2
mm mm mm mm mm mm mm mm
127550.0100 6 13 57 6 127550.0400 12 26 83 12
127550.0200 8 16 63 8 127550.0500 16 32 92 16
127550.0300 10 22 72 10 127550.0600 20 38 104 20
1 27620 Solid carbide end mill for aluminium FUTURO
VHM λ: 45º Z
γ: 12º 2
N
Cu, AI

Type W, with Weldon flat, centre cut, angle of twist 45°, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127620.0100 3 8 6 57 127620.0700 12 26 12 83
127620.0200 4 11 6 57 127620.0800 14 26 14 83
127620.0300 5 13 6 57 127620.0900 16 32 16 92
127620.0400 6 13 6 57 127620.1000 18 32 18 92
127620.0500 8 19 8 63 127620.1100 20 38 20 104
127620.0600 10 22 10 72

1 27640 Solid carbide end mill for aluminium FUTURO
VHM TiAIN λ: 45º Z
γ: 12º 2
N
Cu, AI

Type W, TiAlN, with Weldon flat, centre cut, angle of twist 45°, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127640.0100 3 8 6 57 127640.0600 10 22 10 72
127640.0200 4 11 6 57 127640.0700 12 26 12 83
127640.0300 5 13 6 57 127640.0900 16 32 16 92
127640.0400 6 13 6 57 127640.1100 20 38 20 104
127640.0500 8 19 8 63
528 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
