Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 27650 Solid carbide end mill for aluminium FUTURO

VHM λ: 45º Z
γ: 12º 2
N
Cu, AI

Type W, without flat, centre cut, angle of twist 45°, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127650.0100 3 8 6 57 127650.0500 8 19 8 63
127650.0200 4 11 6 57 127650.0600 10 22 10 72
127650.0300 5 13 6 57 127650.0700 12 26 12 83
127650.0400 6 13 6 57 127650.0800 16 32 16 92
1 27680 Solid carbide end mill for aluminium FUTURO
VHM λ: 30º Z
γ: 15º 3
P K N
≤ 600 Cu, AI

Type WR, roughing profile, with Weldon flat, angle of twist 30°, centre cut, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127680.0100 6 16 6 57 127680.0700 16 32 16 92
127680.0300 8 16 8 63 127680.0900 20 38 20 104
127680.0500 10 22 10 72 127680.1000 25 45 25 121
127680.0600 12 26 12 83
1 27900 Assorted solid carbide fnishing end mills FUTURO
VHM TiAIN λ: 30º Z
4
P K S H
Ni 44-56
≤ 900 HRC
Type N, TiAlN, 4 mm and greater with Weldon flat, angle of twist 30°, centre cut.
Application
For materials with hardness up to 56 HRC.
Scope of supply: 6 pcs in threaded holder
Order ID d1
mm
127900.0100 3, 4, 6, 8, 10, 12
