Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
127130 Solid carbide finishing end mill FUTURO

VHM TiAIN λ: 30º Z
γ: 10º 4
P M K N S
≤ 900 Cu Ni
AI≥4%Si ≤ 900
Type N, TiAlN, sizes 3 mm and greater with Weldon flat, angle of twist 30°, centre cut, works
standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127130.0100 2 7 3 38 127130.0900 8 19 8 63
127130.0200 3 8 6 57 127130.1100 10 22 10 72
127130.0300 3.5 10 6 57 127130.1200 12 26 12 83
127130.0400 4 11 6 57 127130.1300 14 26 14 83
127130.0500 4.5 11 6 57 127130.1400 16 32 16 92
127130.0600 5 13 6 57 127130.1500 18 32 18 92
127130.0700 6 13 6 57 127130.1600 20 38 20 104
127140 Solid carbide finishing end mill FUTURO
VHM TiAIN λ: 30º Z
γ: 12º 4
P M K N
≤ 900 Cu
AI≥4%Si
Type N, TiAlN, without flat, angle of twist 30°, centre cut, works standard, extra long.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127140.0100 3 30 3 75 127140.0500 8 50 8 150
127140.0200 4 30 4 75 127140.0600 10 60 10 150
127140.0300 5 40 5 100 127140.0700 12 75 12 150
127140.0400 6 50 6 150
127150 Solid carbide finishing end mill FUTURO
VHM λ: 30º Z
γ: 10º 3
P M K N
≤ 850 ≤ 900 Cu, AI

Type N, with Weldon flat, angle of twist 30°, centre cut, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127150.0100 2 3 6 50 127150.0700 10 19 10 72
127150.0200 3 7 6 57 127150.0800 12 22 12 83
127150.0300 4 8 6 57 127150.1000 16 26 16 92
127150.0400 5 10 6 57 127150.1100 18 26 18 92
127150.0500 6 10 6 57 127150.1200 20 32 20 104
127150.0600 8 16 8 63

127160 Solid carbide finishing end mill FUTURO
VHM TiAIN λ: 30º Z
γ: 10º 3
P M K N S
≤ 900 Cu, AI Ni
≤ 900
Type N, TiAlN, with Weldon flat, angle of twist 30°, centre cut, works standard.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
127160.0100 2 3 6 50 127160.0700 10 19 10 72
127160.0200 3 7 6 57 127160.0800 12 22 12 83
127160.0300 4 8 6 57 127160.0900 14 22 14 83
127160.0400 5 10 6 57 127160.1000 16 26 16 92
127160.0500 6 10 6 57 127160.1200 20 32 20 104
127160.0600 8 16 8 63
Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 523
