Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 27520 Solid carbide power end mill FUTURO

VHM TiAIN λ: 50º Z
γ: 9º 3-4
P M S
Ti-Ni

Type N, TiAlN, with Weldon flat, angle of twist 50°, works standard.
Application
Especially well suited to machining stainless steel, titanium, Inconel.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Z Order ID d1 l2 d2 l1 Z
mm mm mm mm mm mm mm mm
127520.0100 6 13 6 50 3 127520.0500 16 32 16 90 3
127520.0200 8 19 8 60 3 127520.0700 20 38 20 100 4
127520.0300 10 22 10 70 3 127520.0800 25 45 25 120 4
127520.0400 12 25 12 75 3
1 27525 Solid carbide fnishing end mill FUTURO
VHM TiAIN λ: 35º Z
γ: 10º 4
P M S
Ti-Ni

Type N, TiAlN, with Weldon flat, angle of twist 35°, works standard.
Application
Especially well suited to machining stainless steel, titanium, Inconel.
Tolerance d2: h6
Order ID d1 d2 l1 l2 Order ID d1 d2 l1 l2
mm mm mm mm mm mm mm mm
127525.0100 2 6 40 6 127525.0800 8 8 60 19
127525.0200 2.5 6 40 8 127525.0900 10 10 70 22
127525.0300 3 6 45 8 127525.1000 12 12 75 26
127525.0400 3.5 6 45 10 127525.1100 16 16 100 32
127525.0500 4 6 45 11 127525.1200 20 20 105 38
127525.0600 5 6 50 13 127525.1300 25 25 120 45
127525.0700 6 6 50 13
1 27530 Solid carbide roughing end mill FUTURO
VHM TiAIN λ: 30º Z
γ: 9º 3-4
P K S
Ni
≤ 900
Type Standard, TiAlN, long,
Application
For general use with easily machined steels.
Tolerances: d1: h10 ; d2: h6
Order ID d1 l2 d2 l1 Z Order ID d1 l2 d2 l1 Z
mm mm mm mm mm mm mm mm
127530.0100 6 16 6 57 3 127530.0400 12 26 12 83 4
127530.0200 8 16 8 63 3 127530.0500 16 32 16 92 4
127530.0300 10 22 10 72 4 127530.0600 20 38 20 104 4
