HSS milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
116160 Economy end mill FUTURO

HSS-E λ: 30º Z
Co8 γ: 11º 3
P M K N
≤ 850 ≤ 900 Cu
AI≤4%Si
Type N, HSSE-Co8, angle of twist 30°, centre cut, works standard, long.
Tolerances: d1: e8 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
116160.0100 2 7 6 38 116160.0900 6 13 6 44
116160.0200 2.5 8 6 39 116160.1000 6.5 16 8 48
116160.0300 3 8 6 39 116160.1100 7 16 8 48
116160.0400 3.5 10 6 41 116160.1200 8 19 8 51
116160.0500 4 11 6 42 116160.1300 8.5 19 10 56
116160.0600 4.5 11 6 42 116160.1400 9 19 10 56
116160.0700 5 13 6 44 116160.1500 10 22 10 59
116160.0800 5.5 13 6 44
116180 Economy end mill FUTURO
HSS-E Futura λ: 30º Z
Co8 γ: 11º 3

P M K N S
Cu Ti-Ni
≤ 900
Type N, Futura coating, HSSE-Co8, angle of twist 30°, centre cut, works standard, long.
Tolerances: d1: e8 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
116180.0100 2 7 6 38 116180.0800 5.5 13 6 44
116180.0200 2.5 8 6 39 116180.0900 6 13 6 44
116180.0300 3 8 6 39 116180.1000 7 16 8 48
116180.0400 3.5 10 6 41 116180.1100 8 19 8 51
116180.0500 4 11 6 42 116180.1200 9 19 10 56
116180.0600 4.5 11 6 42 116180.1300 10 22 10 59
116180.0700 5 13 6 44
116200 Slot cutter FUTURO
HSS-PM TiAIN λ: 30º Z
γ: 6º 3

P K N
Cu

Type N-HSC, TiAIN, ASP 60, angle of twist 30°, centre cut, DIN 327.
Tolerances: d1: e8 ; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
116200.0100 1 2.5 6 47 116200.1000 10 13 10 63
116200.0200 2 4 6 48 116200.1100 12 16 12 73
116200.0300 3 5 6 49 116200.1200 14 16 12 73
116200.0400 4 7 6 51 116200.1300 16 19 16 79
116200.0500 5 8 6 52 116200.1400 18 19 16 79
116200.0600 6 8 6 52 116200.1500 20 22 20 88
116200.0700 7 10 10 60 116200.1600 22 22 20 88
116200.0800 8 11 10 61 116200.1700 25 26 25 102
116200.0900 9 11 10 61

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 435
