Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
066132 Go thread ring gauge FUTURO NIHS
Go - HSS-PM - 20 mm
SwissMade - NIHS standard tolerance, with green-anodised Ø 20 mm aluminium handle.
Note:
NIHS standard tolerance NT/RT and DIN tolerances available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
066132.0040 S0.40 0.100 066132.0090 S0.90 0.225
066132.0050 S0.50 0.125 066132.0100 S1.00 0.250
066132.0060 S0.60 0.150 066132.0120 S1.20 0.250
066132.0070 S0.70 0.175 066132.0140 S1.40 0.300
066132.0080 S0.80 0.200 066132.0160 S1.60 0.350
066134 NoGo thread ring gauge FUTURO NIHS
NoGo - HSS-PM - 20 mm
SwissMade - NIHS standard tolerance, with red-anodised Ø 20 mm aluminium handle.
Note:
NIHS standard tolerance NT/RT and DIN tolerances available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
066134.0040 S0.40 0.100 066134.0090 S0.90 0.225
066134.0050 S0.50 0.125 066134.0100 S1.00 0.250
066134.0060 S0.60 0.150 066134.0120 S1.20 0.250
066134.0070 S0.70 0.175 066134.0140 S1.40 0.300
066134.0080 S0.80 0.200 066134.0160 S1.60 0.350

346 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
