Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
066092 NoGo thread plug gauge FUTURO NIHS NT/RT
NoGo - Carbide - 3 mm
SwissMade - Carbide to NIHS-NT/RT tolerance, with red-anodised Ø 3 mm aluminium handle.
Order ID Thread Pitch L1 Order ID Thread Pitch L1
mm mm mm mm
066092.0030 S0.30 0.080 1.0 066092.0080 S0.80 0.200 3.5
066092.0035 S0.35 0.090 1.3 066092.0090 S0.90 0.225 4.0
066092.0040 S0.40 0.100 2.0 066092.0100 S1.00 0.250 4.0
066092.0050 S0.50 0.125 2.5 066092.0120 S1.20 0.250 5.0
066092.0060 S0.60 0.150 3.0 066092.0140 S1.40 0.300 5.0
066092.0070 S0.70 0.175 3.0
066094 Go thread plug gauge FUTURO NIHS RT
Go - Carbide - 3 mm
SwissMade - Carbide to NIHS RT standard tolerance, with green-anodised Ø 3 mm aluminium
handle.
Order ID Thread Pitch L1 Order ID Thread Pitch L1
mm mm mm mm
066094.0030 S0.30 0.080 1.0 066094.0080 S0.80 0.200 3.5
066094.0035 S0.35 0.090 1.3 066094.0090 S0.90 0.225 4.0
066094.0040 S0.40 0.100 2.0 066094.0100 S1.00 0.250 4.0
066094.0050 S0.50 0.125 2.5 066094.0120 S1.20 0.250 5.0
066094.0060 S0.60 0.150 3.0 066094.0140 S1.40 0.300 5.0
066094.0070 S0.70 0.175 3.0
066098 Go thread plug gauge FUTURO NIHS NT-L
Go - HM - 3 mm
SwissMade - Carbide left-hand thread to NIHS-NT standard tolerance, with green-anodised Ø
3 mm aluminium handle.
Order ID Thread Pitch L1 Order ID Thread Pitch L1
mm mm mm mm
066098.0050 S0.50 0.125 2.5 066098.0090 S0.90 0.225 4.0
066098.0060 S0.60 0.150 3.0 066098.0100 S1.00 0.250 4.0
066098.0070 S0.70 0.175 3.0 066098.0120 S1.20 0.250 5.0
066098.0080 S0.80 0.200 3.5
066100 NoGo thread plug gauge FUTURO NIHS NT/RT-L
NoGo - HM - 3 mm
SwissMade - Carbide left-hand thread to NIHS-NT/RT-L standard tolerance, with red-anodised
Ø 3 mm aluminium handle.
Order ID Thread Pitch L1 Order ID Thread Pitch L1
mm mm mm mm
066100.0050 S0.50 0.125 2.5 066100.0090 S0.90 0.225 4.0
066100.0060 S0.60 0.150 3.0 066100.0100 S1.00 0.250 4.0
066100.0070 S0.70 0.175 3.0 066100.0120 S1.20 0.250 5.0
066100.0080 S0.80 0.200 3.5
066105 Go thread plug gauge FUTURO ISO 5H
Go - Carbide - 3 / 6 mm
SwissMade - Carbide to ISO 5H standard tolerance, with green-anodised aluminium handle Ø
3 / 6 mm.
Order ID Thread Pitch L1 Handle Ø
mm mm mm
066105.0100 M1.00 0.25 5.0 3
066105.0125 M1.20 0.25 5.0 3
066105.0145 M1.40 0.30 6.0 3
066105.0200 M2.00 0.20 5.0 6
066105.0225 M2.20 0.25 5.0 6
066107 NoGo thread plug gauge FUTURO ISO 5H
NoGo - Carbide - 3 / 6 mm
SwissMade - Carbide to ISO 5H standard tolerance, with red-anodised aluminium handle Ø 3
/ 6 mm.
Order ID Thread Pitch L1 Handle Ø
mm mm mm
066107.0100 M1.00 0.25 5.0 3
066107.0125 M1.20 0.25 5.0 3
066107.0145 M1.40 0.30 6 3
066107.0225 M2.20 0.25 5.0 6
