Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
068110 Sensor for TESTO 110 / 720
NTC type temperature sensor.
Appropriate accessories:
068190 Wireless sensor
Additional sensors upon request
Note:
t99: Time until sensor shows a 99% accurate value on the display.
Order ID Designation t99 Range Accuracy
s °C
068110.0100 Immersion/penetration probe 10 -50...+150 ±0.2° C (-25 ... +74.9° C)
±0.4° C (+75...+99.9° C)
±0.5% (+100 ... +150° C)
068110.0200 Food probe 8 -50...+150 ±0.2° C (-25 ... +74.9° C)
±0.4° C (+75...+99.9° C)
±0.5% (+100 ... +150° C)
068110.0300 Surface probe 35 -50...+150 ±0.2° C (-25 ... +74.9° C)
±0.4° C (+75...+99.9° C)
±0.5% (+100 ... +150° C)
068110.0400 Air probe 60 -50...+150 ±0.2° C (-25 ... +80° C)
±0.4° C (-50...-25° C / +80...150°
C)
068140 Temperature measuring instrument TESTO 720
A highly accurate measuring instrument for use with PT-100 and NTC sensors.
Features:
Large, illuminated display
HOLD function
Min/Max memory
audible alarm (tolerance exceeded).
Package contents:
Delivered in transport packaging with test report, without sensor.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Appropriate accessories:
068110; 068150 Sensor
068200 Accessories
068280 Printer
Order ID 068140.0100
Type 720
Range °C -100...+800
Resolution °C 0.1
Width mm 64
Height mm 40
Length mm 182
Weight kg 0.171
068150 Sensor for TESTO 720
Temperature sensor Type Pt100.
Appropriate accessories:
068110 Sensors
Additional sensors upon request
Note:
* Class A: ±0.15°C or ±0.002 x temperature
1)
**Class B: ±0.3°C or ±0.005 x temperature
1)
whichever is greatest
1)
t99: time until sensor shows an up to 99% accurate value on the display.
Order ID Designation t99 Range Accuracy
s °C
068150.0100 Dip/insertion probe 12 -50...+400 ±0.15° C*
068150.0200 Surface probe 40 -50...+400 ±0.3° C**
068150.0300 Air probe 70 -50...+400 ±0.15° C*

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 349
