                                065827   NoGo thread ring gauge FUTURO - 6g
                                Metric fine - ISO thread to DIN13 standard, made of gauge steel, hardened and stress-relieved.
                                Appropriate accessories:
                                458240 Protection and packaging box UniBox
                                 Order ID    Thread    Pitch  Order ID    Thread     Pitch
                                                        mm                           mm
                                 065827.1700  M12       1.5   065827.2700  M30       1.5
                                 065827.1800  M14       1.5   065827.2800  M32       1.5
                                 065827.1900  M16       1.5   065827.2900  M35       1.5
                                 065827.2000  M18       1.5   065827.3000  M36       1.5
                                 065827.2100  M20       1.5   065827.3100  M40       1.5
                                 065827.2200  M22       1.5   065827.3200  M42       1.5
                                 065827.2300  M24       1.5   065827.3300  M45       1.5
                                 065827.2400  M25       1.5   065827.3400  M48       1.5
                                 065827.2500  M27       1.5   065827.3500  M50       1.5
                                 065827.2600  M28       1.5
                                065860   Go thread ring gauge JBO - WG
                                Whitworth pipe thread G - (British Standard pipe thread) to DIN EN ISO 228, tolerance class A.
                                Note:
                                Other tolerance classes and left-hand thread on request
                                Appropriate accessories:
                                458240 Protection and packaging box UniBox
                                 Order ID  Thread Threads/inch  Ø  Order ID  Thread  Threads/inch  Ø
                                                         mm                            mm
                                 065860.0100 G1/8“  28   9.728  065860.0700  G7/8“  14  30.201
        Go thread ring gauge, Whitworth  065860.0200 G1/4“  19  13.157 065860.0800  G1“  11  33.249
                                 065860.0300 G3/8“  19  16.662 065860.0900 G1 1/4“  11  41.910
                                 065860.0400 G1/2“  14  20.955 065860.1000 G1 1/2“  11  47.803
                                 065860.0500 G5/8“  14  22.911 065860.1100 G1 3/4“  11  53.746
                                 065860.0600 G3/4“  14  26.441 065860.1200  G2“  11   59.614
                                065960   Go thread ring gauge JBO - UNC
                                UNC - (Unified National Coarse thread) to ANSI B 1.1 standard, tolerance class 2A.
                                Note:
                                Left-hand thread on request
                                Appropriate accessories:
                                458240 Protection and packaging box UniBox
                                 Order ID  Thread  Threads/  Ø  Order ID  Thread  Threads/inch  Ø
                                                    inch
                                                          mm                           mm
          Go thread ring gauge, UNC  065960.0100 UNCNr. 4  40  2.845 065960.0900 UNC7/16“  14  11.113
                                 065960.0200 UNCNr. 6  32  3.505 065960.1000 UNC1/2“  13  12.700
                                 065960.0300 UNCNr. 8  32  4.166 065960.1100 UNC9/16“  12  14.288
                                 065960.0400 UNCNr. 10  24  4.826 065960.1200 UNC5/8“  11  15.875
                                 065960.0500 UNCNr. 12  24  5.486 065960.1300 UNC3/4“  10  19.050
                                 065960.0600 UNC1/4“  20  6.350 065960.1400 UNC7/8“  9  22.225
                                 065960.0700 UNC5/16“  18  7.938 065960.1500  UNC1“  8  25.400
                                 065960.0800 UNC3/8“  16  9.525
                                065970   Go thread ring gauge JBO - UNF
                                UNF - (Unified National Fine thread) to ANSI B 1.1 standard, tolerance class 2A.
                                Note:
                                Left-hand thread on request
                                Appropriate accessories:
                                458240 Protection and packaging box UniBox
                                 Order ID  Thread  Threads/inch  Ø  Order ID  Thread  Threads/inch  Ø
                                                          mm                           mm
                                 065970.0100 UNFNr. 4  48  2.845 065970.0900 UNF7/16“  20  11.113
          Go thread ring gauge, UNF  065970.0200 UNFNr. 6  40  3.505 065970.1000 UNF1/2“  20  12.700
                                 065970.0300 UNFNr. 8  36  4.166 065970.1100 UNF9/16“  18  14.288
                                 065970.0400 UNFNr. 10  32  4.826 065970.1200 UNF5/8“  18  15.875
                                 065970.0500 UNFNr. 12  28  5.486 065970.1300 UNF3/4“  16  19.050
                                 065970.0600 UNF1/4“  28  6.350 065970.1400 UNF7/8“  14  22.225
                                 065970.0700 UNF5/16“  24  7.938 065970.1500  UNF1“  12  25.400
                                 065970.0800 UNF3/8“  24  9.525
