Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
068000 Thermometer TESTO 905
Miniature, rapid thermometer with large range. The sensor, a Type K thermocouple, is excellent
for taking quick measurements in fluids, air, and soft or powdery media.
Designs:
068000.0100 Type T1: Penetration sensor
068000.0200 Type T2: Surface sensor
Features:
High accuracy
Rotating display
Large, fast display
Package contents:
Delivered in transport packaging, including fastening clip.
Appropriate batteries:
3 pieces 055050.1400 - CR2032 / 3.0 V (included in scope of delivery).
Order ID Type Range Resolution Accuracy Weight
°C °C kg
068000.0100 T1 -50...+350 0.1 ±1°C (-50...+99.9°C) 0.08
±1% v.Mw.
068000.0200 T2 -50...+350 0.1 ±1°C (-50...+99.9°C) 0.08
±1% v.Mw.
068005 Thermometer TESTO 810
The measuring device in pocket size for measuring air temperature and infrared surface tempe-
rature.
Features:
IR measurement with 1-spot laser
Temperature difference display
Hold /Max./ Min. function
Dimensions 119 x 46 x 25 mm
Air temperature:
Measurement range -10°C...+50°C
Resolution 0.1°C
Accuracy ±0.5°C
Surface temperature:
Measuring range: -30°...300°C
Resolution: 0.1°C
Accuracy:
(-30°...+100°C) ±2.0°C
(residual) ±2% of measured value
Optics: 6:1
Package contents:
Deliverd with hand loop, belt carrying case, protective cap and calibration report.
Appropriate batteries:
2 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Type
068005.0100 810
068040 Temperature measuring instrument TESTO 925 / 922
An all-rounder with large, illuminated display, Hold button and Min/Max memory. Used with Type
K „NiCr-Ni“ sensor (fixed or with wireless connection).
Designs:
068040.0100 Type925:
1 channel, Audible alarm
068040.0200 Type922:
2 channels (for comparative measurement), Temperature difference indication, Cyclical printing of
measurements
Package contents:
Delivered in transport packaging with test report without sensor.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery). TESTO 925
Appropriate accessories:
068070; 168190 Sensor
068200 Accessories
068280 Printer
Order ID 068040.0100 068040.0200
Type 925 922
Range °C -50...+1000 -50...+1000
Resolution °C 0.1 / 1 (>200°C) 0.1 / 1 (>200°C)
Width mm 64 64
Height mm 40 40
Length mm 182 182
Weight kg 0.171 0.171

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 347
