Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
066109 Go thread plug gauge FUTURO ISO 6H
Go - Carbide - 3 / 6 mm
SwissMade - Carbide to ISO 6H standard tolerance, with green-anodised aluminium handle Ø
3 / 6 mm.
Order ID Thread Pitch L1 Handle Ø
mm mm mm
066109.0160 M1.60 0.35 6.0 3
066109.0180 M1.80 0.35 6.0 3
066109.0200 M2.00 0.40 6.0 6
066109.0220 M2.20 0.45 8.0 6
066109.0250 M2.50 0.45 8.0 6
066109.0305 M3.00 0.50 8.0 6
066111 NoGo thread plug gauge FUTURO ISO 6H
NoGo - Carbide - 3 / 6 mm
SwissMade - Carbide to ISO 6H standard tolerance, with red-anodised aluminium handle Ø 3
/ 6 mm.
Order ID Thread Pitch L1 Handle Ø
mm mm mm
066111.0160 M1.60 0.35 6.0 3
066111.0180 M1.80 0.35 6.0 3
066111.0200 M2.00 0.40 6.0 6
066111.0220 M2.20 0.45 8.0 6
066111.0250 M2.50 0.45 8.0 6
066111.0305 M3.00 0.50 8.0 6
066120 Go thread ring gauge FUTURO NIHS
Go - HSS-PM - 6 mm
SwissMade - NIHS standard tolerance, with green-anodised Ø 6 mm aluminium handle.
Note:
NIHS standard tolerance NT/RT and DIN tolerances available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
066120.0035 S0.35 0.090 066120.0090 S0.90 0.225
066120.0040 S0.40 0.100 066120.0100 S1.00 0.250
066120.0050 S0.50 0.125 066120.0120 S1.20 0.250
066120.0060 S0.60 0.150 066120.0140 S1.40 0.300
066120.0070 S0.70 0.175 066120.0160 S1.60 0.350
066120.0080 S0.80 0.200
066122 NoGo thread ring gauge FUTURO NIHS
NoGo - HSS-PM - 6 mm
SwissMade - NIHS standard tolerance, with red-anodised Ø 6 mm aluminium handle.
Note:
NIHS standard tolerance NT/RT and DIN tolerances available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
066122.0035 S0.35 0.090 066122.0090 S0.90 0.225
066122.0040 S0.40 0.100 066122.0100 S1.00 0.250
066122.0050 S0.50 0.125 066122.0120 S1.20 0.250
066122.0060 S0.60 0.150 066122.0140 S1.40 0.300
066122.0070 S0.70 0.175 066122.0160 S1.60 0.350
066122.0080 S0.80 0.200
066124 Go/NoGo thread ring gauge FUTURO NIHS
Go/NoGo - HSS-PM - 6 mm
SwissMade - NIHS standard tolerance, with black-anodised Ø 6 mm aluminium handle.
Note:
NIHS standard tolerance NT/RT and DIN tolerances available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
066124.0035 S0.35 0.090 066124.0090 S0.90 0.225
066124.0040 S0.40 0.100 066124.0100 S1.00 0.250
066124.0050 S0.50 0.125 066124.0120 S1.20 0.250
066124.0060 S0.60 0.150 066124.0140 S1.40 0.300
066124.0070 S0.70 0.175 066124.0160 S1.60 0.350
066124.0080 S0.80 0.200
