Physical measuring instruments Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
068175 Thermometer digital
Professional 1- or 2-channel temperature measuring instrument for K-type thermal probe connec-
tion. Short measurement times and laboratory accuracy. Integrated control sensor, large display
with backlighting for easy reading.
Designs:
068175.0200: with extra wire probe 068178.0100
Features:
Display 45 mm
HOLD function
MAX function
Units °C, °F, K
Package contents:
Delivered in case incl. wire probe 068178.0100.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Appropriate accessories:
068178 Sensor
Order ID Type Range Resolution Accuracy
°C °C °C
068175.0100 FT 1300-1 -50...1300 0.1 0.5 % / + 1
068175.0200 FT 1300-2 -50...1300 0.1 0.5 % / + 1
068178 Probe for thermometer digital
Order ID Designation Cable length Range
m °C
068178.0100 Flexible wire probe, Ø 2.5 mm 1 -50...+300
068178.0200 Flexible wire probe steel, Ø 2.0 mm 1 -50...+450
068178.0300 Surface angle sensor 1.5 -50...+450
068178.0400 Air temperature sensor, probe length 210 mm 1.5 -50...+800
068178.0500 All-purpose sensor, Ø 3.0 mm, sensor 76 mm (total -50...+900
length 120 mm)
068178.0600 Surface sensor -50...+900
068190 Wireless probes TESTO
Radio range up to approx. 20 m (open air). Code 100 is needed as initial equipment for the measu-
ring instrument.
Note:
t99: Time until sensor shows a 99% accurate value on the display.
Order ID Designation t99 Range
068190.0100 s °C
068190.0100 Wireless module for measuring instrument TESTO - -
068190.0200 Hand-held wireless unit TESTO incl. TE adapter - -
068190.0200 068190.0300 068190.0300 Wireless head dip/insertion probe 10 -50...+350
can be placed on wireless handle TE
fits TESTO 922 / 925
068190.0400 Wireless head surface probe 5 -50...+350
068190.0400 068190.1000 can be placed on wireless handle TE
fits TESTO 922 / 925

068200 Accessories TESTO
Order ID Designation
068200.0600 Silicon heat sink paste
068200.0700 Emission tape TESTO
068200.1000 TopSafe for TESTO TESTO 110 / 625 / 720 / 925
068200.1100 TopSafe for TESTO 922
068200.1300 Ready-for-use bag for TESTO 110 / 720 / 922 / 925
