Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
065785 NoGo thread ring gauge JBO - 6g
Metric fine - ISO thread to DIN 13 standard.
Note:
Thread ring gauges with other pitches and left-hand thread on request
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065785.0010 M2.5 0.35 065785.0470 M14 1.5
065785.0020 M3 0.35 065785.0480 M15 1.5 No-Go thread ring gauge, metric fine
065785.0030 M3.5 0.35 065785.0490 M16 1.5
065785.0040 M4 0.5 065785.0500 M17 1.5
065785.0050 M4.5 0.5 065785.0510 M18 1.5
065785.0060 M5 0.5 065785.0520 M20 1.5
065785.0070 M5.5 0.5 065785.0530 M22 1.5
065785.0080 M6 0.5 065785.0540 M24 1.5
065785.0090 M7 0.5 065785.0550 M25 1.5
065785.0100 M8 0.5 065785.0560 M26 1.5
065785.0110 M9 0.5 065785.0570 M27 1.5
065785.0120 M10 0.5 065785.0580 M28 1.5
065785.0130 M5 0.75 065785.0590 M30 1.5
065785.0140 M6 0.75 065785.0600 M32 1.5
065785.0150 M7 0.75 065785.0610 M33 1.5
065785.0160 M8 0.75 065785.0620 M35 1.5
065785.0170 M9 0.75 065785.0630 M36 1.5
065785.0180 M10 0.75 065785.0640 M39 1.5
065785.0190 M11 0.75 065785.0650 M40 1.5
065785.0200 M12 0.75 065785.0660 M42 1.5
065785.0210 M14 0.75 065785.0670 M45 1.5
065785.0220 M15 0.75 065785.0680 M48 1.5
065785.0230 M16 0.75 065785.0690 M50 1.5
065785.0240 M18 0.75 065785.0700 M52 1.5
065785.0250 M20 0.75 065785.0710 M55 1.5
065785.0260 M8 1 065785.0720 M56 1.5
065785.0270 M9 1 065785.0730 M58 1.5
065785.0280 M10 1 065785.0740 M60 1.5
065785.0290 M11 1 065785.0750 M62 1.5
065785.0300 M12 1 065785.0760 M18 2
065785.0310 M14 1 065785.0770 M20 2
065785.0320 M15 1 065785.0780 M22 2
065785.0330 M16 1 065785.0790 M24 2
065785.0340 M17 1 065785.0800 M25 2
065785.0350 M18 1 065785.0810 M27 2
065785.0360 M20 1 065785.0820 M28 2
065785.0370 M22 1 065785.0830 M30 2
065785.0380 M24 1 065785.0840 M32 2
065785.0390 M25 1 065785.0850 M33 2
065785.0400 M27 1 065785.0860 M36 2
065785.0410 M28 1 065785.0870 M39 2
065785.0420 M30 1 065785.0880 M40 2
065785.0430 M10 1.25 065785.0890 M30 3
065785.0440 M12 1.25 065785.0900 M33 3
065785.0450 M14 1.25 065785.0910 M36 3
065785.0460 M12 1.5 065785.0920 M39 3
065825 Go thread ring gauge FUTURO - 6g
Metric fine - ISO thread to DIN 13 standard, made of gauge steel, hardened and stress-relieved.
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065825.1700 M12 1.5 065825.2700 M30 1.5
065825.1800 M14 1.5 065825.2800 M32 1.5
065825.1900 M16 1.5 065825.2900 M35 1.5
065825.2000 M18 1.5 065825.3000 M36 1.5
065825.2100 M20 1.5 065825.3100 M40 1.5
065825.2200 M22 1.5 065825.3200 M42 1.5
065825.2300 M24 1.5 065825.3300 M45 1.5 Go ring gauge, metric fine
065825.2400 M25 1.5 065825.3400 M48 1.5
065825.2500 M27 1.5 065825.3500 M50 1.5
065825.2600 M28 1.5
