065600 Go thread ring gauge JBO - 6g
Metric - ISO thread to DIN 13. To M1.4 in 6h*.
Note:
Thread ring gauges with other pitches and left-hand thread on request
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065600.0100 M1* 0.25 065600.1800 M8 1.25
065600.0200 M1.1* 0.25 065600.1900 M9 1.25 Go thread ring gauge, metric
065600.0300 M1.2* 0.25 065600.2000 M10 1.5
065600.0400 M1.4* 0.3 065600.2100 M11 1.5
065600.0500 M1.6 0.35 065600.2200 M12 1.75
065600.0600 M1.8 0.35 065600.2300 M14 2
065600.0700 M2 0.4 065600.2400 M16 2
065600.0800 M2.2 0.45 065600.2500 M18 2.5
065600.0900 M2.5 0.45 065600.2600 M20 2.5
065600.1000 M2.6 0.45 065600.2700 M22 2.5
065600.1100 M3 0.5 065600.2800 M24 3
065600.1200 M3.5 0.6 065600.2900 M27 3
065600.1300 M4 0.7 065600.3000 M30 3.5
065600.1400 M4.5 0.75 065600.3100 M33 3.5
065600.1500 M5 0.8 065600.3200 M36 4
065600.1600 M6 1 065600.3300 M39 4
065600.1700 M7 1
065610 NoGo thread ring gauge JBO - 6g
Metric - ISO thread to DIN 13 standard. Up to M1.4 in 6h*.
Note:
Thread ring gauges with other pitches and left-hand thread on request
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065610.0100 M1* 0.25 065610.1800 M8 1.25
065610.0200 M1.1* 0.25 065610.1900 M9 1.25 No-Go thread ring gauge, metric
065610.0300 M1.2* 0.25 065610.2000 M10 1.5
065610.0400 M1.4* 0.3 065610.2100 M11 1.5
065610.0500 M1.6 0.35 065610.2200 M12 1.75
065610.0600 M1.8 0.35 065610.2300 M14 2
065610.0700 M2 0.4 065610.2400 M16 2
065610.0800 M2.2 0.45 065610.2500 M18 2.5
065610.0900 M2.5 0.45 065610.2600 M20 2.5
065610.1000 M2.6 0.45 065610.2700 M22 2.5
065610.1100 M3 0.5 065610.2800 M24 3
065610.1200 M3.5 0.6 065610.2900 M27 3
065610.1300 M4 0.7 065610.3000 M30 3.5
065610.1400 M4.5 0.75 065610.3100 M33 3.5
065610.1500 M5 0.8 065610.3200 M36 4
065610.1600 M6 1 065610.3300 M39 4
065610.1700 M7 1

065725 Go thread ring gauge FUTURO - 6g
Metric - ISO thread to ISO 1502 Standard, made of gauge steel, hardened and stress-relieved.
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065725.0100 M2 0.4 065725.1300 M16 2
065725.0200 M2.5 0.45 065725.1400 M18 2.5
065725.0300 M3 0.5 065725.1500 M20 2.5
065725.0400 M3.5 0.6 065725.1600 M22 2.5
065725.0500 M4 0.7 065725.1700 M24 3
065725.0600 M5 0.8 065725.1800 M27 3 Go ring gauge, metric
065725.0700 M6 1 065725.1900 M30 3.5
065725.0800 M7 1 065725.2000 M36 4
065725.0900 M8 1.25 065725.2100 M42 4.5
065725.1000 M10 1.5 065725.2200 M45 4.5
065725.1100 M12 1.75 065725.2300 M48 5
065725.1200 M14 2
