065302 NoGo thread plug gauge JBO - 6H
Metric fine - to DIN 13
Note:
Other dimensions and left-hand threads available upon request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065302.0660 M42 1.5 065302.0910 M48 2
065302.0670 M45 1.5 065302.0920 M50 2
065302.0680 M48 1.5 065302.0930 M52 2
065302.0690 M50 1.5 065302.0940 M55 2
065302.0700 M52 1.5 065302.0950 M56 2
065302.0710 M55 1.5 065302.0960 M58 2
065302.0720 M56 1.5 065302.0970 M60 2
065302.0730 M58 1.5 065302.1020 M42 3
065302.0740 M60 1.5 065302.1030 M45 3
065302.0750 M62 1.5 065302.1040 M48 3
065302.0890 M42 2 065302.1050 M52 3
065302.0900 M45 2
065310 Thread limit plug gauge JBO - 6H
Metric fine - to DIN 13. Go end DLC-coated to increase durability, surface quality and useful life.
Package contents:
With DLC coating Delivered incl. factory certificate.
Appropriate accessories:
458220; 558230 Protection and packaging tube
Note:
Other dimensions and left-hand threads available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065310.0100 M4 0.5 065310.0800 M8 1
065310.0200 M5 0.5 065310.0900 M10 1
065310.0300 M6 0.5 065310.1000 M12 1
065310.0400 M6 0.75 065310.1100 M14 1
065310.0500 M8 0.75 065310.1200 M16 1
065310.0600 M10 0.75 065310.1300 M18 1
065310.0700 M12 0.75 065310.1400 M20 1
079890 Screw selector
German - Made of plastic, 131 x 250 mm, with the most important sizes of ISO standard thread
and ISO fine threads M3...M125, design sizes, strength properties, tractive force, tightening torque
for screws and nuts.
Order ID Size
mm
079890.0100 M3...M125
