Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
065150 Thread limit plug gauge JBO - 6H
Metric - to DIN 13.
Note:
For threads larger than M40 the Go and No-Go ends are supplied individually (065151 / 065152)
*Standard tolerance 5H to DIN 13
Other dimensions and left-hand threads available upon request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065150.0100 M1* 0.25 065150.2000 M10 1.5
065150.0200 M1.1* 0.25 065150.2100 M11 1.5
065150.0300 M1.2* 0.25 065150.2200 M12 1.75
065150.0400 M1.4* 0.3 065150.2300 M14 2
065150.0500 M1.6 0.35 065150.2400 M16 2
065150.0600 M1.8 0.35 065150.2500 M18 2.5
065150.0700 M2 0.4 065150.2600 M20 2.5
065150.0800 M2.2 0.45 065150.2700 M22 2.5
065150.0900 M2.5 0.45 065150.2800 M24 3
065150.1000 M2.6 0.45 065150.2900 M27 3
065150.1100 M3.0 0.5 065150.3000 M30 3.5
065150.1200 M3.5 0.6 065150.3100 M33 3.5
065150.1300 M4 0.7 065150.3200 M36 4
065150.1400 M4.5 0.75 065150.3300 M39 4
065150.1500 M5 0.8 065150.3400 M42 4.5
065150.1600 M6 1 065150.3500 M45 4.5
065150.1700 M7 1 065150.3600 M48 5
065150.1800 M8 1.25 065150.3700 M52 5
065150.1900 M9 1.25 065150.3800 M56 5.5
065151 Go Thread plug gauge JBO - 6H
Metric - to DIN 13
Note:
Other dimensions and left-hand threads available upon request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065151.3400 M42 4.5 065151.3700 M52 5
065151.3500 M45 4.5 065151.3800 M56 5.5
065151.3600 M48 5

065152 NoGo thread plug gauge JBO - 6H
Metric - to DIN 13
Note:
Other dimensions and left-hand threads available upon request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065152.3400 M42 4.5 065152.3700 M52 5
065152.3500 M45 4.5 065152.3800 M56 5.5
065152.3600 M48 5
065160 Thread limit plug gauge JBO - 6H
Metric - to DIN 13. Go end DLC-coated to increase durability, surface quality and useful life.
Package contents:
Delivered incl. factory certificate. Go side DLC-coated
Appropriate accessories:
458220; 558230 Protection and packaging tube
Note:
Other dimensions and left-hand threads available upon request
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065160.0100 M3 0.5 065160.0500 M8 1.25
065160.0200 M4 0.7 065160.0600 M10 1.5
065160.0300 M5 0.8 065160.0700 M12 1.75
065160.0400 M6 1 065160.0900 M20 2.5
