Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
064790 Snap gauge - h6
Two-ended limit gauge made of gauge steel, hardened, stress-relieved and fine lapped. Suitable for
checking shafts for clearance/transition/press fits.
Note:
Other ISO tolerances on request
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064790.0100 6 064790.1500 20 064790.2900 44
064790.0200 7 064790.1600 22 064790.3000 45
064790.0300 8 064790.1700 24 064790.3100 50
064790.0400 9 064790.1800 25 064790.3200 55
064790.0500 10 064790.1900 26 064790.3300 60
064790.0600 11 064790.2000 28 064790.3400 65
064790.0700 12 064790.2100 30 064790.3500 70
064790.0800 13 064790.2200 32 064790.3600 75
064790.0900 14 064790.2300 34 064790.3700 80
064790.1000 15 064790.2400 35 064790.3800 85
064790.1100 16 064790.2500 36 064790.3900 90
064790.1200 17 064790.2600 38 064790.4000 95
064790.1300 18 064790.2700 40 064790.4100 100
064790.1400 19 064790.2800 42
064800 ISATOOL adjustable limit gauge
Adjustable
With flat measurement surfaces, one side with anvil, the other with 2 adjustable plug gauges,
hardened, ground, lapped, and plane-parallel.
Note:
On request: measurement ranges up to 295 mm, and version with undercut gauge jaws for un-
dercut measurements.
Tolerance setting at extra charge.
Order ID Range Order ID Range Order ID Range
mm mm mm
064800.0100 0...5 064800.0400 15...20 064800.0700 32...38
064800.0200 5...10 064800.0500 19...26 064800.0800 38...44
064800.0300 10...15 064800.0600 26...32
064960 Ring gauge MICROTOOL
Swiss Made from first-class quality gauge steel to DIN 2250 C standard, for setting and checking
measuring devices.
Note:
Intermediate dimensions, adjusting rings to DIN 2250-B standard, or with LTC TiN coating available
on request
Appropriate accessories:
458240 Protection and packaging box UniBox
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064960.0100 3 064960.1400 13 064960.2700 45
064960.0200 4 064960.1500 14 064960.2800 50
064960.0300 5 064960.1600 15 064960.2900 55
064960.0400 5.5 064960.1700 16 064960.3000 60
064960.0500 6 064960.1800 17 064960.3100 65
064960.0600 7 064960.1900 17.5 064960.3200 70
064960.0700 8 064960.2000 18 064960.3300 75
064960.0800 8.5 064960.2100 19 064960.3400 80
064960.0900 9 064960.2200 20 064960.3500 85
064960.1000 10 064960.2300 25 064960.3600 90
064960.1100 11 064960.2400 30 064960.3700 95
064960.1200 12 064960.2500 35 064960.3800 100
064960.1300 12.5 064960.2600 40
