Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
065300 Thread limit plug gauge JBO - 6H
Metric fine - to DIN 13
Note:
For threads larger than M40 the Go and No-Go ends are supplied individually (065301 / 165302
Other dimensions or left-hand thread on request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065300.0010 M2.5 0.35 065300.0540 M24 1.5
065300.0020 M3 0.35 065300.0550 M25 1.5
065300.0030 M3.5 0.35 065300.0560 M26 1.5
065300.0040 M4 0.5 065300.0570 M27 1.5
065300.0050 M4.5 0.5 065300.0580 M28 1.5
065300.0060 M5 0.5 065300.0590 M30 1.5
065300.0070 M5.5 0.5 065300.0600 M32 1.5
065300.0080 M6 0.5 065300.0610 M33 1.5
065300.0090 M7 0.5 065300.0620 M35 1.5
065300.0100 M8 0.5 065300.0630 M36 1.5
065300.0110 M9 0.5 065300.0640 M39 1.5
065300.0120 M10 0.5 065300.0650 M40 1.5
065300.0130 M5 0.75 065300.0660 M42 1.5
065300.0140 M6 0.75 065300.0670 M45 1.5
065300.0150 M7 0.75 065300.0680 M48 1.5
065300.0160 M8 0.75 065300.0690 M50 1.5
065300.0170 M9 0.75 065300.0700 M52 1.5
065300.0180 M10 0.75 065300.0710 M55 1.5
065300.0190 M11 0.75 065300.0720 M56 1.5
065300.0200 M12 0.75 065300.0730 M58 1.5
065300.0210 M14 0.75 065300.0740 M60 1.5
065300.0220 M15 0.75 065300.0750 M62 1.5
065300.0230 M16 0.75 065300.0760 M18 2
065300.0240 M18 0.75 065300.0770 M20 2
065300.0250 M20 0.75 065300.0780 M22 2
065300.0260 M8 1 065300.0790 M24 2
065300.0270 M9 1 065300.0800 M25 2
065300.0280 M10 1 065300.0810 M27 2
065300.0290 M11 1 065300.0820 M28 2
065300.0300 M12 1 065300.0830 M30 2
065300.0310 M14 1 065300.0840 M32 2
065300.0320 M15 1 065300.0850 M33 2
065300.0330 M16 1 065300.0860 M36 2
065300.0340 M17 1 065300.0870 M39 2
065300.0350 M18 1 065300.0880 M40 2
065300.0360 M20 1 065300.0890 M42 2
065300.0370 M22 1 065300.0900 M45 2
065300.0380 M24 1 065300.0910 M48 2
065300.0390 M25 1 065300.0920 M50 2
065300.0400 M27 1 065300.0930 M52 2
065300.0410 M28 1 065300.0940 M55 2
065300.0420 M30 1 065300.0950 M56 2
065300.0430 M10 1.25 065300.0960 M58 2
065300.0440 M12 1.25 065300.0970 M60 2
065300.0450 M14 1.25 065300.0980 M30 3
065300.0460 M12 1.5 065300.0990 M33 3
065300.0470 M14 1.5 065300.1000 M36 3
065300.0480 M15 1.5 065300.1010 M39 3
065300.0490 M16 1.5 065300.1020 M42 3
065300.0500 M17 1.5 065300.1030 M45 3
065300.0510 M18 1.5 065300.1040 M48 3
065300.0520 M20 1.5 065300.1050 M52 3
065300.0530 M22 1.5
065301 Go Thread plug gauge JBO - 6H
Metric fine - to DIN 13
Note:
Other dimensions and left-hand threads available upon request
Appropriate accessories:
458220; 558230 Protection and packaging tube
Order ID Thread Pitch Order ID Thread Pitch
mm mm
065301.0660 M42 1.5 065301.0910 M48 2
065301.0670 M45 1.5 065301.0920 M50 2
065301.0680 M48 1.5 065301.0930 M52 2
065301.0690 M50 1.5 065301.0940 M55 2
065301.0700 M52 1.5 065301.0950 M56 2
065301.0710 M55 1.5 065301.0960 M58 2
065301.0720 M56 1.5 065301.0970 M60 2
065301.0730 M58 1.5 065301.1020 M42 3
065301.0740 M60 1.5 065301.1030 M45 3
065301.0750 M62 1.5 065301.1040 M48 3
065301.0890 M42 2 065301.1050 M52 3
065301.0900 M45 2
