064445 Limit plug gauge ISATOOL - H7
Go/NoGo: Gauge steel
Type 10 - First-class quality Swiss-made to ISO Standards. Carefully hardened and aged. Highly
accurate thanks to cryostabilisation (at -85°C). Lightweight construction with anodised aluminium
handle:
Versions:
Go: Gauge steel
No-go: Gauge steel
Note:
Other diameters or tolerances on request
Appropriate accessories:
064530 Wooden case
458220; 558230 Protection and packaging tube
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064445.0100 1.5 064445.2200 20 064445.4300 44
064445.0200 2 064445.2300 21 064445.4400 45
064445.0300 2.5 064445.2400 22 064445.4500 46
064445.0400 3 064445.2500 23 064445.4600 47
064445.0500 3.5 064445.2600 24 064445.4700 48
064445.0600 4 064445.2700 25 064445.4800 50
064445.0700 5 064445.2800 26 064445.4900 52
064445.0800 6 064445.2900 27 064445.5000 55
064445.0900 7 064445.3000 28 064445.5100 58
064445.1000 8 064445.3100 29 064445.5200 60
064445.1100 9 064445.3200 30 064445.5300 62
064445.1200 10 064445.3300 31 064445.5400 65
064445.1300 11 064445.3400 32 064445.5500 68
064445.1400 12 064445.3500 33 064445.5600 70
064445.1500 13 064445.3600 34 064445.5700 72
064445.1600 14 064445.3700 35 064445.5800 75
064445.1700 15 064445.3800 36 064445.5900 80
064445.1800 16 064445.3900 37 064445.6000 85
064445.1900 17 064445.4000 38 064445.6100 90
064445.2000 18 064445.4100 40 064445.6200 95
064445.2100 19 064445.4200 42 064445.6300 100
064450 Limit plug gauge ISATOOL - H7
Go: Hard chrome-plated / NoGo: Gauge steel
Type 11 - First-class quality Swiss-made to ISO Standards. Carefully hardened and aged. Highly
accurate thanks to cryostabilisation (at -85°C). Lightweight construction with anodised aluminium
handle:
Versions:
Go end: Hard chrome-plated
No-Go end: Gauge steel
Note:
Other diameters or tolerances on request
Appropriate accessories:
064530 Wooden case
458220; 558230 Protection and packaging tube
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064450.0400 3 064450.2400 22 064450.4400 45
064450.0500 3.5 064450.2500 23 064450.4500 46
064450.0600 4 064450.2600 24 064450.4600 47
064450.0700 5 064450.2700 25 064450.4700 48
064450.0800 6 064450.2800 26 064450.4800 50
064450.0900 7 064450.2900 27 064450.4900 52
064450.1000 8 064450.3000 28 064450.5000 55
064450.1100 9 064450.3100 29 064450.5100 58
064450.1200 10 064450.3200 30 064450.5200 60
064450.1300 11 064450.3300 31 064450.5300 62
064450.1400 12 064450.3400 32 064450.5400 65
064450.1500 13 064450.3500 33 064450.5500 68
064450.1600 14 064450.3600 34 064450.5600 70
064450.1700 15 064450.3700 35 064450.5700 72
064450.1800 16 064450.3800 36 064450.5800 75
064450.1900 17 064450.3900 37 064450.5900 80
064450.2000 18 064450.4000 38 064450.6000 85
064450.2100 19 064450.4100 40 064450.6100 90
064450.2200 20 064450.4200 42 064450.6200 95
064450.2300 21 064450.4300 44 064450.6300 100
