Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
064370 Limit plug gauge - H7
Go/NoGo: Gauge steel
Body hardened, stabilised and stress-relieved, fine-ground and lapped. With hexagonal handle.
Tolerances to DIN 7162 and DIN 7164.
Versions:
Go end: Gauge steel
No-Go end: Gauge steel
Note:
Other diameters, tolerances or executions on request
Appropriate accessories:
064530 Wooden case
458220; 558230 Protection and packaging tube
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064370.0100 2 064370.2000 21 064370.3900 46
064370.0200 3 064370.2100 22 064370.4000 47
064370.0300 4 064370.2200 23 064370.4100 48
064370.0400 5 064370.2300 24 064370.4200 50
064370.0500 6 064370.2400 25 064370.4300 52
064370.0600 7 064370.2500 26 064370.4400 55
064370.0700 8 064370.2600 27 064370.4500 60
064370.0800 9 064370.2700 28 064370.4600 62
064370.0900 10 064370.2800 30 064370.4700 65
064370.1000 11 064370.2900 32 064370.4800 68
064370.1100 12 064370.3000 34 064370.4900 70
064370.1200 13 064370.3100 35 064370.5000 72
064370.1300 14 064370.3200 36 064370.5100 75
064370.1400 15 064370.3300 37 064370.5200 80
064370.1500 16 064370.3400 38 064370.5300 85
064370.1600 17 064370.3500 40 064370.5400 90
064370.1700 18 064370.3600 42 064370.5500 95
064370.1800 19 064370.3700 44 064370.5600 100
064370.1900 20 064370.3800 45
064380 Limit plug gauge - H7
Go: Hard chrome-plated / NoGo: Gauge steel
Body hardened, stabilised and stress-relieved, fine-ground and lapped. With hexagonal handle.
Tolerances to DIN 7162 and DIN 7164.
Versions:
Go end: Hard chrome-plated
No-Go end: Gauge steel
Note:
Other diameters, tolerances or executions on request
Appropriate accessories:
064530 Wooden case
458220; 558230 Protection and packaging tube
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064380.0200 3 064380.1300 14 064380.2500 26
064380.0300 4 064380.1400 15 064380.2600 27
064380.0400 5 064380.1500 16 064380.2700 28
064380.0500 6 064380.1600 17 064380.2800 30
064380.0600 7 064380.1700 18 064380.2900 32
064380.0700 8 064380.1800 19 064380.3000 34
064380.0800 9 064380.1900 20 064380.3100 35
064380.0900 10 064380.2100 22 064380.3200 36
064380.1000 11 064380.2200 23 064380.3400 38
064380.1100 12 064380.2300 24 064380.3500 40
064380.1200 13 064380.2400 25
064390 Limit plug gauge - H7
Go: Carbide / NoGo: Gauge steel
Body hardened, stabilised and stress-relieved, fine-ground and lapped. With hexagonal handle.
Tolerances to DIN 7162 and DIN 7164.
Versions:
Go end: Carbide
No-Go end: Gauge steel
Note:
Other diameters, tolerances or executions (both sides on carbide) and setting rings on carbide on
request
Appropriate accessories:
064530 Wooden case
458220; 558230 Protection and packaging tube
Order ID Nominal Ø Order ID Nominal Ø Order ID Nominal Ø
mm mm mm
064390.0300 4 064390.1100 12 064390.1600 17
064390.0400 5 064390.1200 13 064390.1700 18
064390.0500 6 064390.1300 14 064390.1800 19
064390.0700 8 064390.1400 15 064390.1900 20
064390.0900 10 064390.1500 16
