Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
062920 Precision feeler gauge tape H+S
Stainless spring steel 1.4310 / length 5 m x width 100 mm
Version with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used
for alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate and other sizes available on request.
Package contents:
Thickness ≤ 0.3 mm, supplied in plastic packaging
Thickness > 0.3 mm ≤ 0.5 mm supplied in cardboard sleeve
Thickness > 0.5 mm, supplied without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062920.0050 0.005 ±0.001 062920.1700 0.20 ±0.006
062920.0080 0.008 ±0.001 062920.1720 0.21 ±0.006
062920.0100 0.01 ±0.002 062920.1740 0.22 ±0.006
062920.0200 0.015 ±0.002 062920.1760 0.23 ±0.006 ≤ 0.3 mm
062920.0300 0.02 ±0.002 062920.1780 0.24 ±0.006
062920.0400 0.03 ±0.002 062920.1800 0.25 ±0.007
062920.0500 0.035 ±0.003 062920.1820 0.26 ±0.007
062920.0600 0.04 ±0.003 062920.1840 0.27 ±0.007
062920.0700 0.045 ±0.003 062920.1860 0.28 ±0.007
062920.0800 0.05 ±0.003 062920.1880 0.29 ±0.007
062920.0900 0.055 ±0.003 062920.1900 0.30 ±0.007
062920.1000 0.06 ±0.003 062920.2000 0.35 ±0.008
062920.1100 0.07 ±0.004 062920.2100 0.40 ±0.009
062920.1200 0.08 ±0.004 062920.2200 0.45 ±0.009
062920.1300 0.09 ±0.004 062920.2300 0.50 ±0.010
062920.1400 0.10 ±0.004 062920.2400 0.55 ±0.010
062920.1420 0.11 ±0.004 062920.2500 0.60 ±0.010
062920.1500 0.12 ±0.004 062920.2600 0.65 ±0.012
062920.1520 0.13 ±0.005 062920.2700 0.70 ±0.012
062920.1540 0.14 ±0.005 062920.2800 0.75 ±0.012
062920.1600 0.15 ±0.005 062920.2900 0.80 ±0.013 > 0.3 mm ≤ 0.5 mm
062920.1620 0.16 ±0.005 062920.3000 0.85 ±0.013
062920.1640 0.17 ±0.005 062920.3100 0.90 ±0.013
062920.1650 0.18 ±0.005 062920.3200 0.95 ±0.013
062920.1680 0.19 ±0.005 062920.3300 1.00 ±0.017

062930 Precision feeler gauge tape H+S
Stainless spring steel 1.4310 / length 5 m x width 150 mm
Version with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used
for alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate and other sizes available on request.
Package contents:
Thickness ≤ 0.25 mm, supplied in plastic packaging
Thickness > 0.25 mm ≤ 0.5 mm, supplied in cardboard sleeve
Thickness > 0.5 mm, supplied without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062930.0100 0.025 ±0.002 062930.0900 0.40 ±0.009
062930.0200 0.05 ±0.003 062930.1000 0.50 ±0.010
062930.0300 0.075 ±0.004 062930.1100 0.60 ±0.010
062930.0400 0.10 ±0.004 062930.1200 0.70 ±0.012 > 0.5 mm
062930.0500 0.15 ±0.005 062930.1300 0.80 ±0.013
062930.0600 0.20 ±0.006 062930.1400 0.90 ±0.013
062930.0700 0.25 ±0.007 062930.1500 1.00 ±0.017
062930.0800 0.30 ±0.007
062950 Precision feeler gauge tape H+S
Brass 2.0321 / length 5 m x width 150 mm
Brass with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used for
alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate and other sizes available on request.
Package contents:
Thickness ≤ 0.3 mm, supplied in plastic packaging
Thickness > 0.3 mm ≤ 0.5 mm supplied in cardboard sleeve
Thickness > 0.5 mm, supplied without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062950.0100 0.01 ±0.002 062950.0800 0.25 ±0.007
062950.0110 0.02 ±0.002 062950.0900 0.30 ±0.007
062950.0200 0.025 ±0.002 062950.1000 0.40 ±0.009
062950.0210 0.03 ±0.002 062950.1100 0.50 ±0.010 ≤ 0.3 mm
062950.0220 0.04 ±0.003 062950.1200 0.60 ±0.010
062950.0300 0.05 ±0.003 062950.1300 0.70 ±0.012
062950.0400 0.075 ±0.004 062950.1400 0.80 ±0.013
062950.0500 0.10 ±0.004 062950.1500 0.90 ±0.013
062950.0600 0.15 ±0.005 062950.1600 1.00 ±0.017
062950.0700 0.20 ±0.006
