Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
063307 Ceramic parallel gauge block set FUTURO
Tolerance class 0, DIN EN ISO 3650 - For testing outside micrometers. The set consists of 5
parallel gauge blocks:
5.1 / 10.3 / 15.0 / 20.2 / 25.0 mm.
Package contents:
Delivered in own case incl. cotton gloves and calibration certificate.
Order ID Class of accuracy
063307.0100 0
With calibration certificate
063309 Carbide parallel gauge block set
Tolerance class 0, DIN EN ISO 3650 - For testing outside micrometers. The set consists of 8 par-
allel gauge blocks: 5.1 / 10.3 / 15.0 / 20.2 / 25 / 50 / 75 / 100 mm.
Note:
other tolerance classes on request
Package contents:
with calibration certificate Delivered in own case incl. calibration certificate.
Order ID Class of accuracy
063309.0100 0

063312 Steel parallel gauge block set FUTURO
Tolerance class 1 - For testing outside micrometers to DIN 863 Part 1. The set consists of 5 parallel
gauge blocks:
5.1 / 10.3 / 15.0 / 20.2 / 25.0 mm.
Package contents:
Delivered in own case incl. calibration certificate.
Order ID Class of accuracy
063312.0100 1

With calibration certificate
063314 Ceramic parallel gauge block set FUTURO
Tolerance class 1 - For testing outside micrometers to DIN 863 Part 1.
Set consisting of:
5 parallel gauge blocks 5.1 / 10.3 / 15.0 / 20.2 / 25.0 mm
1 planar glass Ø 32 x 12mm
Package contents:
Delivered in own case incl. calibration certificate.
Order ID Class of accuracy
063314.0100 1
With calibration certificate
079810 ISO Tolerance slide gauge
German - French - Made of plastic, 300 x 88 mm, with nominal dimensions for locations of dril-
lings and shafts from 1...180 mm.
Order ID Size
mm
079810.0100 Ø 1...180
079920 ISO tolerance key
Multilingual - In sealed plastic case, 110 x 60 x 30 mm, well protected from dirt and dust. Suitable
for determining tolerance values to ISO 286-1988 standard; for range IT1 - IT16, has a full list of
ISO tolerances up to nominal size 500 mm, with over 6400 pairs of tolerance values. Designed for
use in the workshop, planning processes, design departments etc.
Order ID 079920.0100
