Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
063140 Precision foils H+S
Stainless spring steel strip 1.4310 / length 500 mm x width 150 mm
For shimming, mounting, adjusting, etc.
Note:
Factory certificate available upon request.
Package contents:
Delivered in packs of 5.
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
063140.0100 0.025 ±0.002 063140.1100 0.60 ±0.010
063140.0200 0.05 ±0.003 063140.1200 0.70 ±0.012
063140.0300 0.075 ±0.004 063140.1300 0.80 ±0.013
063140.0400 0.10 ±0.004 063140.1400 0.90 ±0.013
063140.0500 0.15 ±0.005 063140.1500 1.00 ±0.017
063140.0600 0.20 ±0.006 063140.1600 1.20 ±0.017
063140.0700 0.25 ±0.007 063140.1700 1.50 ±0.020
063140.0800 0.30 ±0.007 063140.1800 1.80 ±0.023
063140.0900 0.40 ±0.009 063140.1900 2.00 ±0.025
063140.1000 0.50 ±0.010
063150 Set of precision foils H+S
Stainless spring steel strip 1.4310 / length 500 mm x width 100 mm
For shimming, mounting, adjusting, etc.
Note:
Factory certificate available upon request.
Package contents:
Delivered in set of 9 blades as shown in the table.
Order ID Thickness Tolerance
mm mm
063150.0100 0.02 / 0.05 / 0.1 / 0.15 / 0.2 / 0.3 / 0.4 / 0.5 / 1.0 ±0.002…0.017

063160 Set of precision foils H+S
Stainless spring steel strip 1.4310 / length 500 mm x width 150 mm
For shimming, mounting, adjusting, etc.
Note:
Factory certificate available upon request.
Package contents:
Delivered in set of 10 blades as shown in the table.
Order ID Thickness Tolerance
mm mm
063160.0100 0.025 / 0.05 / 0.075 / 0.1 / 0.15 / 0.2 / 0.25 ±0.002…0.010
0.3 / 0.4 / 0.5

063170 Set of precision foils H+S
Stainless spring steel strip 1.4310 / length 500 mm x width 100 mm
For shimming, mounting, adjusting, etc.
Note:
Factory certificate available upon request.
Package contents:
Delivered in set of 11 blades as shown in the table.
Order ID Thickness Tolerance
mm mm
063170.0100 0.02 / 0.05 / 0.1 / 0.15 / 0.2 / 0.25 / 0.3 / 0.35 ±0.002…0.010
0.4 / 0.45 / 0.5

063180 Set of precision foils H+S
Stainless spring steel strip 1.4310 / length 500 mm x width 100 mm
For shimming, mounting, adjusting, etc.
Note:
Factory certificate available upon request.
Package contents:
Delivered in set of 11 blades as shown in the table.
Order ID Thickness Tolerance
mm mm
063180.0100 0.5 / 0.55 / 0.6 / 0.65 / 0.7 / 0.75 / 0.8 / 0.85 ±0.010…0.017
0.9 / 0.95 / 1.0
