Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
062830 Precision gauge strip H+S
Spring steel strip 1.1274 / length 2 m x width 12.7 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate available upon request.
Package contents:
Delivered in plastic box.
*only available in stainless spring steel strip
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062830.0100 0.005* ±0.001 062830.1700 0.30 ±0.007
062830.0200 0.01* ±0.002 062830.1800 0.35 ±0.008
062830.0300 0.02 ±0.002 062830.1900 0.40 ±0.009
062830.0400 0.03 ±0.002 062830.2000 0.45 ±0.009
062830.0500 0.04 ±0.003 062830.2100 0.50 ±0.010
062830.0600 0.05 ±0.003 062830.2200 0.55 ±0.010
062830.0700 0.06 ±0.003 062830.2300 0.60 ±0.010
062830.0800 0.07 ±0.004 062830.2400 0.65 ±0.012
062830.0900 0.08 ±0.004 062830.2500 0.70 ±0.012
062830.1000 0.09 ±0.004 062830.2600 0.75 ±0.012
062830.1100 0.10 ±0.004 062830.2700 0.80 ±0.013
062830.1200 0.12 ±0.004 062830.2800 0.85 ±0.013
062830.1300 0.15 ±0.005 062830.2900 0.90 ±0.013
062830.1400 0.18 ±0.005 062830.3000 0.95 ±0.013
062830.1500 0.20 ±0.006 062830.3100 1.00 ±0.017
062830.1600 0.25 ±0.007
062840 Precision gauge strip H+S
Spring steel strip 1.1274 / length 5 m x width 12.7 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate available upon request.
Package contents:
Delivered in plastic box.
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062840.0200 0.02 ±0.002 062840.1700 0.35 ±0.008
062840.0300 0.03 ±0.002 062840.1800 0.40 ±0.009
062840.0400 0.04 ±0.003 062840.1900 0.45 ±0.009
062840.0500 0.05 ±0.003 062840.2000 0.50 ±0.010
062840.0600 0.06 ±0.003 062840.2100 0.55 ±0.010
062840.0700 0.07 ±0.004 062840.2200 0.60 ±0.010
062840.0800 0.08 ±0.004 062840.2300 0.65 ±0.012
062840.0900 0.09 ±0.004 062840.2400 0.70 ±0.012
062840.1000 0.10 ±0.004 062840.2500 0.75 ±0.012
062840.1100 0.12 ±0.004 062840.2600 0.80 ±0.013
062840.1200 0.15 ±0.005 062840.2700 0.85 ±0.013
062840.1300 0.18 ±0.005 062840.2800 0.90 ±0.013
062840.1400 0.20 ±0.006 062840.2900 0.95 ±0.013
062840.1500 0.25 ±0.007 062840.3000 1.00 ±0.017
062840.1600 0.30 ±0.007
062850 Precision gauge strip H+S
Spring steel strip 1.1274 / length 10 m x width 12.7 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate available upon request.
Package contents:
Delivered in plastic box.
*only available in stainless spring steel strip
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062850.0100 0.005* ±0.001 062850.1700 0.30 ±0.007
062850.0200 0.01* ±0.002 062850.1800 0.35 ±0.008
062850.0300 0.02 ±0.002 062850.1900 0.40 ±0.009
062850.0400 0.03 ±0.002 062850.2000 0.45 ±0.009
062850.0500 0.04 ±0.003 062850.2100 0.50 ±0.010
062850.0600 0.05 ±0.003 062850.2200 0.55 ±0.010
062850.0700 0.06 ±0.003 062850.2300 0.60 ±0.010
062850.0800 0.07 ±0.004 062850.2400 0.65 ±0.012
062850.0900 0.08 ±0.004 062850.2500 0.70 ±0.012
062850.1000 0.09 ±0.004 062850.2600 0.75 ±0.012
062850.1100 0.10 ±0.004 062850.2700 0.80 ±0.013
062850.1200 0.12 ±0.004 062850.2800 0.85 ±0.013
062850.1300 0.15 ±0.005 062850.2900 0.90 ±0.013
062850.1400 0.18 ±0.005 062850.3000 0.95 ±0.013
062850.1500 0.20 ±0.006 062850.3100 1.00 ±0.017
062850.1600 0.25 ±0.007
