Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
062900 Precision gauge strip H+S
Stainless spring steel strip 1.4310 / length 5 m x width 12.7 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate available upon request.
Package contents:
Delivered in plastic box.
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062900.0100 0.005 ±0.001 062900.1300 0.20 ±0.006
062900.0200 0.01 ±0.002 062900.1320 0.21 ±0.006
062900.0300 0.02 ±0.002 062900.1340 0.22 ±0.006
062900.0400 0.03 ±0.002 062900.1350 0.23 ±0.006
062900.0500 0.04 ±0.003 062900.1360 0.24 ±0.006
062900.0600 0.05 ±0.003 062900.1400 0.25 ±0.007
062900.0700 0.06 ±0.003 062900.1420 0.26 ±0.007
062900.0800 0.07 ±0.004 062900.1440 0.27 ±0.007
062900.0900 0.08 ±0.004 062900.1460 0.28 ±0.007
062900.1000 0.09 ±0.004 062900.1480 0.29 ±0.007
062900.1100 0.10 ±0.004 062900.1500 0.30 ±0.007
062900.1120 0.11 ±0.004 062900.1600 0.40 ±0.009
062900.1130 0.12 ±0.004 062900.1700 0.45 ±0.009
062900.1140 0.13 ±0.005 062900.1800 0.50 ±0.010
062900.1150 0.14 ±0.005 062900.1900 0.60 ±0.010
062900.1200 0.15 ±0.005 062900.2000 0.70 ±0.012
062900.1220 0.16 ±0.005 062900.2100 0.80 ±0.013
062900.1240 0.17 ±0.005 062900.2200 0.90 ±0.013
062900.1260 0.18 ±0.005 062900.2300 1.00 ±0.017
062900.1280 0.19 ±0.005
062905 Precision feeler gauge tape H+S
Stainless spring steel 1.4310 / length 5 m x width 25 mm
Version with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used
for alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate on request.
Package contents:
Thickness ≤ 0.3 mm, supplied in plastic packaging
Thickness ≥ 0.4 mm ≤ 0.8 mm, supplied in metal box
Thickness ≥ 0.9 mm, supplied without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062905.0200 0.01 ±0.002 062905.1000 0.40 ±0.009
≤ 0.3 mm
062905.0300 0.02 ±0.002 062905.1100 0.50 ±0.010
062905.0400 0.05 ±0.003 062905.1200 0.60 ±0.010
062905.0500 0.10 ±0.004 062905.1300 0.70 ±0.012
062905.0600 0.15 ±0.005 062905.1400 0.80 ±0.013
062905.0700 0.20 ±0.006 062905.1500 0.90 ±0.013
062905.0800 0.25 ±0.007 062905.1600 1.00 ±0.017
062905.0900 0.30 ±0.007
062910 Precision feeler gauge tape H+S
Stainless spring steel 1.4310 / length 5 m x width 50 mm
Version with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used
for alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate on request.
Package contents:
Thickness ≤ 0.3 mm, supplied in plastic packaging
Thickness ≥ 0.4 mm ≤ 0.8 mm, supplied in metal box
Thickness ≥ 0.9 mm, supplied without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062910.0100 0.005 ±0.001 062910.0900 0.30 ±0.007
≥ 0.4 mm ≤ 0.8 mm 062910.0200 0.01 ±0.002 062910.1000 0.40 ±0.009
062910.0300 0.02 ±0.002 062910.1100 0.50 ±0.010
062910.0400 0.05 ±0.003 062910.1200 0.60 ±0.010
062910.0500 0.10 ±0.004 062910.1300 0.70 ±0.012
062910.0600 0.15 ±0.005 062910.1400 0.80 ±0.013
062910.0700 0.20 ±0.006 062910.1500 0.90 ±0.013
062910.0800 0.25 ±0.007 062910.1600 1.00 ±0.017
