Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
062860 Precision feeler gauge tape H+S
Spring steel 1.1274 / length 5 m x width 25 mm
Version with progressively labelled thickness (therefore no mix-ups). Perfect for feeler gauges used
for alignments and adjustments during production, and assembling machine components.
Note:
Factory certificate on request.
Package contents:
Thickness ≤ 0.3 mm, supplied in plastic packaging
Thickness ≥ 0.4 mm ≤ 0.8 mm, supplied in metal box
Thickness ≥ 0.9 mm, supplied without protective packaging
*only available in stainless spring steel (062905)
≤ 0.3 mm
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062860.0300 0.03 ±0.002 062860.1300 0.25 ±0.007
062860.0400 0.04 ±0.003 062860.1400 0.30 ±0.007
062860.0500 0.05 ±0.003 062860.1500 0.40 ±0.009
062860.0600 0.06 ±0.003 062860.1600 0.50 ±0.010
062860.0700 0.07 ±0.004 062860.1700 0.60 ±0.010
062860.0800 0.08 ±0.004 062860.1800 0.70 ±0.012
062860.0900 0.09 ±0.004 062860.1900 0.80 ±0.013
062860.1000 0.10 ±0.004 062860.2000 0.90 ±0.013
062860.1100 0.15 ±0.005 062860.2100 1.00 ±0.017
062860.1200 0.20 ±0.006
≥ 0.4 mm ≤ 0.8 mm

062870 Precision gauge strip H+S
Spring steel strip 1.1274 / length 5 m x width 50 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate and other sizes available upon request.
Package contents:
Package contents ≤ 0.3 mm delivered in plastic packaging
Package contents ≥ 0.35 mm ≤ 0.7 mm delivered in tin canister
Package contents ≥ 0.8 mm delivered without protective packaging
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062870.0100 0.03 ±0.002 062870.1300 0.25 ±0.007
062870.0200 0.04 ±0.003 062870.1400 0.30 ±0.007 ≤ 0.3 mm
062870.0300 0.05 ±0.003 062870.1500 0.35 ±0.008
062870.0400 0.06 ±0.003 062870.1600 0.40 ±0.009
062870.0500 0.07 ±0.004 062870.1700 0.45 ±0.009
062870.0600 0.08 ±0.004 062870.1800 0.50 ±0.010
062870.0700 0.09 ±0.004 062870.1900 0.60 ±0.010
062870.0800 0.10 ±0.004 062870.2000 0.70 ±0.012
062870.0900 0.12 ±0.004 062870.2100 0.80 ±0.013
062870.1000 0.15 ±0.005 062870.2200 0.90 ±0.013
062870.1100 0.18 ±0.005 062870.2300 1.00 ±0.017
062870.1200 0.20 ±0.006
062885 Clamp
For gauge strips with widths 6 and 12.7 mm.
Order ID 062885.0100

062898 Precision gauge strip H+S
Stainless spring steel strip 1.4310 / length 5 m x width 10 mm
Version with progressively labelled thickness (no mix-up as a result). Perfect for alignments and
adjustments during production and assembly of machine components.
Note:
Factory certificate available upon request.
Package contents:
Delivered in plastic box.
Order ID Thickness Tolerance Order ID Thickness Tolerance
mm mm mm mm
062898.0500 0.10 ±0.004 062898.1100 0.50 ±0.010
062898.0600 0.15 ±0.005 062898.1200 0.60 ±0.010
062898.0700 0.20 ±0.006 062898.1300 0.70 ±0.012
062898.0800 0.25 ±0.007 062898.1400 0.80 ±0.013
062898.0900 0.30 ±0.007 062898.1500 0.90 ±0.013
062898.1000 0.40 ±0.009 062898.1600 1.00 ±0.017

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 301
