Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
052386 Cold light source FUTURO LED
Multifunctional cold light source with high powered LED and 2 optical fiber (semi-rigid). The light
intensity is adjustable by a control dial. The brightness of the High Power LED is equivalent to a 120
W hologen cold light source.
Features:
Optical fiber 2-arm, Ø 4 x 470 mm
High Power LED
Package content:
Delivered in transport packaging including optical fiber 2-arm.
Order ID 052386.0100 LED
Type LED / 30 W
Light temperature K 6500
Dimensions WxDxH mm 230 x 185 x 120
Weight kg 3.1
052580 Measurement microscope TM MITUTOYO
Compact design for use in production areas, inspection and measurement rooms for measu-
ring diameters, coordinates, circles, radii, angles, threads, pitches, etc.
Features:
Transmitted light white LED with green filter
Incident light white LED can be rotated and pivoted at will
Turnable eyepiece with angel reading
Light intensity adjustable.
Package contents:
Lens 2x, Eyepiece 15x, LED transmitted and incident light, protective cover, without built-in mi-
crometers (016370).
Appropriates accessories:
Built-in micrometers 016370
Accessories 052590 Application with micrometer (016370)
Lens cleaner 051300 / 152945
Order ID 052580.0101 052580.0201
Type TM-505B / 50 x 50 TM-1005B / 100 x 50
Magnification 30x 30x
Field of vision Ø mm 13 13
Eyepiece rotatable 360°...1° 360°...1°
Range mm 50 x 50 100 x 50
Work piece height max. mm 115 107
Working distance mm 67 67
Weight kg 14 15
052590 Accessories MITUTOYO TM
Order ID Designation
052590.0050 Eyepiece 10x
052590.0100 Eyepiece 15x
052590.0150 Eyepiece 20x
052590.0200 Lens 5x
052590.0300 Lens 2x
052590.0400 Replacement bulb 24V
052590.0510 LED-Ring light Ø 45 / Ø 77 x 22, 24 LED‘s
052804 Base with granite tabletop FUTURO
For use with optical comparators, co-ordinate measuring devices etc. The anti-vibration adjustable
feet with levelling screws can be used to adapt the working height.
Features:
Hard stone plate of black granit
Flatness to DIN 876/2
Dimension 820 x 580 x 50 mm
Drawer cabinet
Robust steel tube construction
Painted with RAL 7035
Drawers 50 / 100 / 150mm
Working height approx. 750 mm
Lockable, load capacity 100 kg
Package contents:
Base frame including 3-point support kit, 2 anti-tilt devices and 4 levelling feets.
052804.3200: without granite table 052804.5000
052804.5000: with granite table
Order ID Version
052804.3200 without granite tabletop
052804.5000 with granite tabletop
