Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
052360 Stereo zoom microscope FUTURO BZS
Robust stereo microscope with flex arm stand and zoom lens for inspection jobs during produc-
tion, continuously adjustable from 7x... 45x.
Designs:
052360.0500 : with flex arm stand
Features:
Microscope head with 10x eyepieces
Fine adjustment
The eyepieces can be adjusted from 50...75 mm
Package content:
Stand and microscope head, eye guards.
052360.0500
Appropiates accessories:
Cold-light source 052386
LED ring light FUTURO 052370.5000
Optics cleaning 051300
Order ID 052360.0500
Magnification 7x...45x
Zoom 0.7...4.5
Field of vision Ø mm 28...4
Working distance mm 100
Work piece height max. mm 230
Base plate mm 230 x 230
Working radius mm 500
Total height mm 580
052375 Stereo microscope FUTURO EDU CAM
Stereo microscope with integrated colour camera (USB connection) for high-resolution, high-
intensity, sharp images. Ideal for use in testing rooms, in goods receiving or in production.
Features:
Revolving objective 1x / 2x / 4x
Enlargement 10x / 20x / 40x
Eye distance adjustable 50...75 mm
Field of view ~18 mm (at 1.0x)
Working distance ~ 50 mm
Incident light LED, can be switched on and off or dimmed
Transmitted light LED, can be switched on and off or dimmed
Stand with fine adjustment
CMOS colour camera 3.2 MP (USB connection)
Package content:
Stand and microscope head, eye guards, dust cover, power supply, software ImageFocus, compu-
ter not included.
Appropriate batteries:
3 pieces 055060.0220 - HR6 / 2300 mAh / 4 x 1.2V (AA) / B4 (included in scope of delivery).
052375.0500
Appropiates accessories:
Accessories 052370
Cold-light souce 052386
Lens cleaner 051300
Order ID 052375.0500
Magnification 10x / 20x / 40x
Field of vision Ø mm 18 / 8 / 4
Object disk Ø mm 60
Working distance mm 55
Work piece height max. mm 25
052385 Cold-light source PHOTONIC
Extremely high light intensity cold-light source with 2 optical fiber (semi-rigid), electronically regu-
lated. Absolutely even illumination due to patented directed lighting. Housing with filter slot on
the side.
Features:
Optical fiber 2-arm, Ø 4 x 500 mm
Halogen reflector lamp 30 W / 10.8 V
Power consumption 50 VA / 240 V
Package content:
Delivered in transport packaging.
Order ID 052385.0100
Type PL 1000 / 30W
Light temperature K 3200
Dimensions WxDxH mm 168 x 268 x 120
Halogen Weight kg 1.3
