Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
052148 Stereo inspection system
MANTIS Elite-Cam (with integrated camera)
Clear, distortion-free, three-dimensional magnification. Viewing screen instead of eyepieces allows
fatigue-free, ergonomic inspection in a similar manner to large magnifying glasses. This system
has an integrated camera and software for recording images.
Designs:
052148.0030 MANTIS Elite-Cam HD Universal :
Stereo inspection system (with integrated camera and uEye software) and swivelling stands,
head can be tilted 25°
Application Mantis Universal 052148.0040 MANTIS Elite-Cam HD TS :
Stereo inspection system (with integrated camera and uEye software) and table tripod with LED
transillumination
Features:
Projection head with factory-integrated camera
Continuous live image on monitor
Lens changer for 2 lenses
Stores the image recordings in: BMP, JPEG, PNG
Package contents:
MANTIS Elite projection head with integrated camera and LED incident light
Application Mantis TS Swivelling stand (Universal) or table tripod (TS)
Dust cover, plug-in power supply, USB cable 1m
Image recording software uEye (English) on CD
PC, monitor and objective are not included.
Appropriates accessories:
Accessories 052146
Lens cleaner 051300 / 152945
Note:
Lenses Elite-models must be ordered separately 052146.
Order ID Type Magnification Weight
kg
052148.0030 MANTIS Elite-Cam HD Universal 2x/4x/6x/8x/10x/15x/20x 6.3
052148.0040 MANTIS Elite-Cam HD TS 2x/4x/6x/8x/10x/15x/20x 8.0
052151 Stereo zoom microscope ZEISS Stemi 305
Compact and user-friendly stereo microscope (Greenough principle) with 5:1 zoom for industrial
production environments, laboratories or schools.
The high-quality optics render a crisp and three-dimensional image possible.
The integrated LED illumination makes it possible to optimally illuminate the specimens.
Designs:
052151.0100 EDU :
LED spot with zoom, height adjustable, flat transmitted light base for brightfield and darkfield
EDU MAT illumination
052151.0200 MAT :
LED ring light segmentable, ESD characteristic
052151.0300 LAB :
Double-armed swan neck, transillumination base with swivel mirror
Package contents:
Delivered in transport packaging with dust cover.
Appropiates accessories:
Accessories 052170
Cold-light souce 052385 / 152386
LAB Lens cleaner 051300
Order ID Type Magnification Zoom Field of vision Ø Working distance
mm mm
052151.0100 EDU 8x...40x 5 : 1 29 110
052151.0200 MAT 8x...40x 5 : 1 29 110
052151.0300 LAB 8x...40x 5 : 1 29 110

052170 Accessories ZEISS
Order ID Designation
052170.1000 Dust cover 300 x 190 x 400 mm
052170.1500 Eyepiece cup Stemi 305
052170.1505 Controller K LED
052170.1510 Ring lamp can be segmented K LED
052170.1515 Double spot light K LED
