Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
052190 Stereo microscope LEICA
S series
Stereo microscope for simple applications, with magnification from 6.3x to 40x (depending on
model).
Designs:
052190.0100 ...052190.0200 : Sturdy stand with plastic black/white plate for contrast optimiza-
tion, post with precision adjustment. Eyepieces with separate sharpness adjustment, suitable for
spectacle wearers.
Equipped with KL300LED cold light source.
052190.0510 ...052190.0520 : Model with LED2500 incident and transmitted light stand. The
incident and transmitted light, built into the stand, can be switched on in combination or indepen-
dently, and helps ensure sharp, well-lit images. S6E / KL300LED
052190.0840 : Articulated stand model with antistatic ESD horizontal arm. With a small base, lar-
ge working range and a max. extension of 640 mm, it is ideal for the inspection of large specimens
in production and quality control.
Package contents:
Delivered in transport packaging including protective hood.
Appropriates accessories:
Lens cleaner 051300 / 152945
Accessories 052195
Order ID 052190.0100 .0200 .0510 .0520 .0840
Type S4E / KL300LED S6E / KL300LED S4E / LED2500 S6E / LED2500 S6E / ESD
Magnification 6.3x...30x 6.3x...40x 6.3x...30x 6.3x...40x 6.3x...40x
Zoom 4.8 : 1 6.3 : 1 4.8 : 1 6.3 : 1 6.3 : 1 S4E / LED2500
Field of vision mm 36.5 36.5 36.5 36.5 36.5
Ø
Work piece mm 75 75 75 75 300
height max.
Working mm 110 110 110 110 110
distance

052193 Stereo/zoom microscope LEICA
E series
For high-resolution, bright and sharp images with 8x...56x zoom (depending on model). This stereo
zoom microscope with crystal-clear optics can be used for inspection tasks, in quality assurance or
in portable applications thanks to its low weight. The 60° view angle is equally ergonomic for users
of various heights. The eyepiece supports are simultaneously adjustable from 50...75 mm, allowing
optimal adjustment to personal eye levels. The LED incident and transmitted light, built into the
stand, can be switched on in combination or independently.
Designs:
052193.0100 ES2 : 2-step magnification selector
052193.0200 EZ4/10 : with fixed 10x eyepieces
052193.0500 EZ4/O : with open tubes (eyepieces to choose) 052193.0100
052193.0705 EZ4 W : with integrated CMOS camera (5.0 megapixel). Fast, high-resolution live
images can be displayed via HDMI connection on a full HD monitor. Images and films can be stored
on SD card or transferred via Wi-Fi, USB, Ethernet to a PC or tablet.
Package contents:
Delivered in transport packaging.
Model EZ4 W delivered with software (CD), HDMI- and USB cable without SD card.
Appropriates accessories:
Lens cleaner 051300 / 152945
Accessories 052195
Order ID Type Magnification Zoom Field of vision Ø Working distance
mm mm
052193.0100 ES2 10x / 30x 3:1 6.7...20 100 052193.0705
052193.0200 EZ4/10 8x...35x 4.4:1 5.7...25 100
052193.0500 EZ4/O 8x...56x 4.4:1 3.4...25 100
052193.0705 EZ4 W 8x...35x 4.4:1 5.7...25 100
052195 Accessories LEICA microscopes
Order ID Designation
052195.0100 Ocular adjustable for spectacle wearers 10x / 20B - serial E
052195.0200 Ocular adjustable for spectacle wearers 16x / 15B - serial E
052195.1000 Pair eyecups for spectacle wearers
052195.2100 Ring light LED3000 RL with control unit Ø 58/24 - serial A+M

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 255
