164340 High-performance tap FUTURO

HSS-E TiN M ISO 2 B
(6H) 3.5-5.5
P M N
≥ 600 ≤ 900 Cu
≤ 850
Metric ISO thread
With straight flutes and spiral point, made from HSS-E, TiN, tolerance ISO2 / 6H.
Application
For tough materials (stainless).
End section B
Hole type: For through holes.
Designs
M3 - M10: reinforced shank.
M12 - M24: reduced shank.
Order ID d P DIN L l d1 a Ø
mm mm mm mm mm mm
164340.0100 M3 0.5 371 56 10 3.5 2.7 2.5
164340.0200 M4 0.7 371 63 12 4.5 3.4 3.4
164340.0300 M5 0.8 371 70 14 6 4.9 4.2
164340.0400 M6 1 371 80 16 6 4.9 5
164340.0500 M8 1.25 371 90 18 8 6.2 6.8
164340.0600 M10 1.5 371 100 20 10 8 8.5
164340.0700 M12 1.75 376 110 24 9 7 10.2
164340.0800 M16 2 376 110 26 12 9 14
164340.0900 M20 2.5 376 140 32 16 12 17.5
164340.1000 M24 3 376 160 36 18 14.5 21
164350 High-performance tap FUTURO
HSS-E TiN M ISO 2 C
PM (6H) 2-3

P M N
≥ 600 ≤ 900 Cu
≤ 850
Metric ISO thread
With spiral flutes 40°, made from HSSE-PM, TiN, tolerance ISO2 / 6H.
Application
For tough materials (stainless).
End section C
Hole type: For pocket holes.
Designs
M3...M10: reinforced shank.
M12 - M20: reduced shank.
Order ID d P DIN L l d1 a Ø
mm mm mm mm mm mm
164350.0100 M3 0.5 371 56 6 3.5 2.7 2.5
164350.0200 M4 0.7 371 63 7.5 4.5 3.4 3.3
164350.0300 M5 0.8 371 70 8.5 6 4.9 4.2
164350.0400 M6 1 371 80 11 6 4.9 5
164350.0500 M8 1.25 371 90 14 8 6.2 6.8
164350.0600 M10 1.5 371 100 16 10 8 8.5
164350.0700 M12 1.75 376 110 18.5 9 7 10.2
164350.0800 M16 2 376 110 20 12 9 14
164350.0900 M20 2.5 376 140 25 16 12 17.5
164180 Machine tap FUTURO
HSS-E VAP M 6H B
3.5-5.5

P K N
≤ 850 Cu
AI≥4%Si
Metric ISO thread
Type UNI, HSS-E, DIN371, reinforced shank, vaporised, tolerance ISO2/6H.
Application
universally applicable
Chamfer form B
Hole type: through holes
Order ID d P l L d1 a DIN Ø
mm mm mm mm mm mm
164180.0100 M3 0.5 10 56 3.5 2.7 371 2.5
164180.0200 M4 0.7 12 63 4.5 3.4 371 3.3
164180.0300 M5 0.8 14 70 6 4.9 371 4.2
164180.0400 M6 1 16 80 6 4.9 371 5
164180.0500 M8 1.25 18 90 8 6.2 371 6.8
164180.0600 M10 1.5 20 100 10 8 371 8.5
