HSS Drilling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
154150 High-performance drill FUTURO

HSS-E TiAIN WN
PM α: 130º
P M K N S
≤ 900 AI Ti
≥ 4% Si
HSSE-PM, TiAlN-coating, works standard.
Application
Especially stable drill with high wear resistance. Best for use on high-alloy steels, tempered and
case-hardened steels, cast iron, brass and bronze.
Order ID d1 l2 l1 d2 l3 Order ID d1 l2 l1 d2 l3 Order ID d1 l2 l1 d2 l3
mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm
154150.0100 2 24 56 3 28 154150.1200 5.5 57 101 6 36 154150.2300 9 81 131 10 40
154150.0200 2.5 30 62 3 28 154150.1300 5.8 57 101 6 36 154150.2400 9.5 81 131 10 40
154150.0300 3 33 65 3 28 154150.1400 6 57 101 6 36 154150.2500 10 87 137 10 40
154150.0400 3.3 36 68 4 28 154150.1500 6.5 63 107 8 36 154150.2600 10.2 87 144 12 45
154150.0500 3.5 39 71 4 28 154150.1600 6.8 69 113 8 36 154150.2700 10.5 87 144 12 45
154150.0600 3.8 43 75 4 28 154150.1700 7 69 113 8 36 154150.2800 11 94 151 12 45
154150.0700 4 43 75 4 28 154150.1800 7.5 69 113 8 36 154150.2900 11.5 94 151 12 45
154150.0800 4.2 43 87 6 36 154150.1900 7.8 75 119 8 36 154150.3000 12 101 158 12 45
154150.0900 4.5 47 91 6 36 154150.2000 8 75 119 8 36 154150.3100 12.5 101 161 14 45
154150.1000 4.8 52 96 6 36 154150.2100 8.5 75 125 10 40 154150.3200 13 101 161 14 45
154150.1100 5 52 96 6 36 154150.2200 8.8 81 131 10 40
154145 High-performance drill FUTURO
HSS-E TiN DIN
PM α: 130º 338

P M K N S
Ti

HSSE-PM, TiN coating, DIN 338.
Application
Stable twist drill for use in steel and high-strength steel.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154145.0100 1 12 34 154145.2300 3.2 36 65 154145.4500 5.4 57 93 154145.6700 7.6 75 117
154145.0200 1.1 14 36 154145.2400 3.3 36 65 154145.4600 5.5 57 93 154145.6800 7.7 75 117
154145.0300 1.2 16 38 154145.2500 3.4 39 70 154145.4700 5.6 57 93 154145.6900 7.8 75 117
154145.0400 1.3 16 38 154145.2600 3.5 39 70 154145.4800 5.7 57 93 154145.7000 7.9 75 117
154145.0500 1.4 18 40 154145.2700 3.6 39 70 154145.4900 5.8 57 93 154145.7100 8 75 117
154145.0600 1.5 18 40 154145.2800 3.7 39 70 154145.5000 5.9 57 93 154145.7200 8.5 75 117
154145.0700 1.6 20 43 154145.2900 3.8 43 75 154145.5100 6 57 93 154145.7300 8.8 81 125
154145.0800 1.7 20 43 154145.3000 3.9 43 75 154145.5200 6.1 63 101 154145.7400 9 81 125
154145.0900 1.8 22 46 154145.3100 4 43 75 154145.5300 6.2 63 101 154145.7500 9.3 81 125
154145.1000 1.9 22 46 154145.3200 4.1 43 75 154145.5400 6.3 63 101 154145.7600 9.5 81 125
154145.1100 2 24 49 154145.3300 4.2 43 75 154145.5500 6.4 63 101 154145.7700 9.8 87 133
154145.1200 2.1 24 49 154145.3400 4.3 47 80 154145.5600 6.5 63 101 154145.7800 10 87 133
154145.1300 2.2 27 53 154145.3500 4.4 47 80 154145.5700 6.6 63 101 154145.7900 10.2 87 133
154145.1400 2.3 27 53 154145.3600 4.5 47 80 154145.5800 6.7 63 101 154145.8000 10.5 87 133
154145.1500 2.4 30 57 154145.3700 4.6 47 80 154145.5900 6.8 69 109 154145.8100 11 94 142
154145.1600 2.5 30 57 154145.3800 4.7 47 80 154145.6000 6.9 69 109 154145.8200 11.5 94 142
154145.1700 2.6 30 57 154145.3900 4.8 52 86 154145.6100 7 69 109 154145.8300 12 101 151
154145.1800 2.7 33 61 154145.4000 4.9 52 86 154145.6200 7.1 69 109 154145.8400 12.5 101 151
154145.1900 2.8 33 61 154145.4100 5 52 86 154145.6300 7.2 69 109 154145.8500 13 101 151
154145.2000 2.9 33 61 154145.4200 5.1 52 86 154145.6400 7.3 69 109
154145.2100 3 33 61 154145.4300 5.2 52 86 154145.6500 7.4 69 109
154145.2200 3.1 36 65 154145.4400 5.3 52 86 154145.6600 7.5 69 109
