152140 Twist drill TITEX

HSS-E DIN
α: 130º 338
P M N S
≤ 850 Cu Ti-Ni

A1244, Type VA, HSS-E, polished surface; DIN 338.
Application
Heat-resistant twist drill with specially designed geometry for use in hard-to-machine materials
that tend to be highly work-hardening, such as stainless steels, acid- and heat-resistant steels and
titanium.
1 pack contains: 0.3...0.9 mm: 10
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
152140.0010 0.3 3 19 152140.0270 2.9 33 61 152140.0530 5.5 57 93 152140.0790 8.1 75 117
152140.0020 0.4 5 20 152140.0280 3 33 61 152140.0540 5.6 57 93 152140.0800 8.2 75 117
152140.0030 0.5 6 22 152140.0290 3.1 36 65 152140.0550 5.7 57 93 152140.0810 8.3 75 117
152140.0040 0.6 7 24 152140.0300 3.2 36 65 152140.0560 5.8 57 93 152140.0820 8.4 75 117
152140.0050 0.7 9 28 152140.0310 3.3 36 65 152140.0570 5.9 57 93 152140.0830 8.5 75 117
152140.0060 0.8 10 30 152140.0320 3.4 39 70 152140.0580 6 57 93 152140.0840 8.6 81 125
152140.0070 0.9 11 32 152140.0330 3.5 39 70 152140.0590 6.1 63 101 152140.0850 8.7 81 125
152140.0080 1 12 34 152140.0340 3.6 39 70 152140.0600 6.2 63 101 152140.0860 8.8 81 125
152140.0090 1.1 14 36 152140.0350 3.7 39 70 152140.0610 6.3 63 101 152140.0870 8.9 81 125
152140.0100 1.2 16 38 152140.0360 3.8 43 75 152140.0620 6.4 63 101 152140.0880 9 81 125
152140.0110 1.3 16 38 152140.0370 3.9 43 75 152140.0630 6.5 63 101 152140.0890 9.1 81 125
152140.0120 1.4 18 40 152140.0380 4 43 75 152140.0640 6.6 63 101 152140.0900 9.2 81 125
152140.0130 1.5 18 40 152140.0390 4.1 43 75 152140.0650 6.7 63 101 152140.0910 9.3 81 125
152140.0140 1.6 20 43 152140.0400 4.2 43 75 152140.0660 6.8 69 109 152140.0920 9.4 81 125
152140.0150 1.7 20 43 152140.0410 4.3 47 80 152140.0670 6.9 69 109 152140.0930 9.5 81 125
152140.0160 1.8 22 46 152140.0420 4.4 47 80 152140.0680 7 69 109 152140.0940 9.6 87 133
152140.0170 1.9 22 46 152140.0430 4.5 47 80 152140.0690 7.1 69 109 152140.0950 9.7 87 133
152140.0180 2 24 49 152140.0440 4.6 47 80 152140.0700 7.2 69 109 152140.0960 9.8 87 133
152140.0190 2.1 24 49 152140.0450 4.7 47 80 152140.0710 7.3 69 109 152140.0970 9.9 87 133
152140.0200 2.2 27 53 152140.0460 4.8 52 86 152140.0720 7.4 69 109 152140.0980 10 87 133
152140.0210 2.3 27 53 152140.0470 4.9 52 86 152140.0730 7.5 69 109 152140.0990 10.2 87 133
152140.0220 2.4 30 57 152140.0480 5 52 86 152140.0740 7.6 75 117 152140.1000 10.5 87 133
152140.0230 2.5 30 57 152140.0490 5.1 52 86 152140.0750 7.7 75 117 152140.1010 11 94 142
152140.0240 2.6 30 57 152140.0500 5.2 52 86 152140.0760 7.8 75 117 152140.1020 11.5 94 142
152140.0250 2.7 33 61 152140.0510 5.3 52 86 152140.0770 7.9 75 117 152140.1030 12 101 151
152140.0260 2.8 33 61 152140.0520 5.4 57 93 152140.0780 8 75 117
152160 Twist drill GÜHRING
HSS-E DIN
α: 135º 338
P M K S
≥ 850 ≤ 900 Ti-Ni
≤ 1400 ≤ 900
1146, Type N, M42, DIN 338.
Very powerful, stable twist drill of high-alloy Co-Mo steel (8%Co, 10%Mo) with extreme heat
resistance.
Application
Preferred for use on high strength alloys on a Cr-Ni basis, such as Hastelloy, Inconell, Monell, Ni-
monic, rust-, acid- and heat-resistant steels. Also for steels or bronzes up to about 1450 N/mm2.
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
152160.0200 1 12 34 152160.2000 2.8 33 61 152160.3800 4.6 47 80 152160.5600 7.5 69 109
152160.0300 1.1 14 36 152160.2100 2.9 33 61 152160.3900 4.7 47 80 152160.5700 7.8 75 117
152160.0400 1.2 16 38 152160.2200 3 33 61 152160.4000 4.8 52 86 152160.5800 8 75 117
152160.0500 1.3 16 38 152160.2300 3.1 36 65 152160.4100 4.9 52 86 152160.5900 8.5 75 117
152160.0600 1.4 18 40 152160.2400 3.2 36 65 152160.4200 5 52 86 152160.6000 8.8 81 125
152160.0700 1.5 18 40 152160.2500 3.3 36 65 152160.4300 5.1 52 86 152160.6100 9 81 125
152160.0800 1.6 20 43 152160.2600 3.4 39 70 152160.4400 5.2 52 86 152160.6200 9.5 81 125
152160.0900 1.7 20 43 152160.2700 3.5 39 70 152160.4500 5.3 52 86 152160.6300 9.8 87 133
152160.1000 1.8 22 46 152160.2800 3.6 39 70 152160.4600 5.4 57 93 152160.6400 10 87 133
152160.1100 1.9 22 46 152160.2900 3.7 39 70 152160.4700 5.5 57 93 152160.6500 10.2 87 133
152160.1200 2 24 49 152160.3000 3.8 43 75 152160.4800 5.6 57 93 152160.6600 10.5 87 133
152160.1300 2.1 24 49 152160.3100 3.9 43 75 152160.4900 5.7 57 93 152160.6700 11 94 142
152160.1400 2.2 27 53 152160.3200 4 43 75 152160.5000 5.8 57 93 152160.6800 11.5 94 142
152160.1500 2.3 27 53 152160.3300 4.1 43 75 152160.5100 5.9 57 93 152160.6900 12 101 151
152160.1600 2.4 30 57 152160.3400 4.2 43 75 152160.5200 6 57 93 152160.7000 12.5 101 151
152160.1700 2.5 30 57 152160.3500 4.3 47 80 152160.5300 6.5 63 101 152160.7100 13 101 151
152160.1800 2.6 30 57 152160.3600 4.4 47 80 152160.5400 6.8 69 109
152160.1900 2.7 33 61 152160.3700 4.5 47 80 152160.5500 7 69 109
