154240 Twist drill FUTURO

HSS TiN DIN
α: 130º 1897
P M K N S
≤ 900 Cu Ti-Ni

Type VG, TiN, HSCO, DIN 1897, extra short.
Application
Very robust twist drill with outstanding heat resistance. Suitable for hard-to-work materials, such as
stainless and acid-resistant steels (SS steels), spring steels,austenitic steels.
1 pack contains: 0.5...0.9 mm: 10
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
154240.0100 0.5 3 20 154240.2100 2.6 14 43 154240.4100 4.6 24 58 154240.6100 8 37 79
154240.0200 0.7 4.5 23 154240.2200 2.7 16 46 154240.4200 4.7 24 58 154240.6200 8.5 37 79
154240.0300 0.8 5 24 154240.2300 2.8 16 46 154240.4300 4.8 26 62 154240.6300 8.8 40 84
154240.0400 0.9 5.5 25 154240.2400 2.9 16 46 154240.4400 4.9 26 62 154240.6400 9 40 84
154240.0500 1 6 26 154240.2500 3 16 46 154240.4500 5 26 62 154240.6500 9.5 40 84
154240.0600 1.1 7 28 154240.2600 3.1 18 49 154240.4600 5.1 26 62 154240.6600 9.8 43 89
154240.0700 1.2 8 30 154240.2700 3.2 18 49 154240.4700 5.2 26 62 154240.6700 10 43 89
154240.0800 1.3 8 30 154240.2800 3.3 18 49 154240.4800 5.3 26 62 154240.6800 10.2 43 89
154240.0900 1.4 9 32 154240.2900 3.4 20 52 154240.4900 5.4 28 66 154240.6900 10.5 43 89
154240.1000 1.5 9 32 154240.3000 3.5 20 52 154240.5000 5.5 28 66 154240.7000 10.8 47 95
154240.1100 1.6 10 34 154240.3100 3.6 20 52 154240.5100 5.6 28 66 154240.7100 11 47 95
154240.1200 1.7 10 34 154240.3200 3.7 20 52 154240.5200 5.7 28 66 154240.7200 11.5 47 95
154240.1300 1.8 11 36 154240.3300 3.8 22 55 154240.5300 5.8 28 66 154240.7300 12 51 102
154240.1400 1.9 11 36 154240.3400 3.9 22 55 154240.5400 5.9 28 66 154240.7400 12.5 51 102
154240.1500 2 12 38 154240.3500 4 22 55 154240.5500 6 28 66 154240.7500 13 51 102
154240.1600 2.1 12 38 154240.3600 4.1 22 55 154240.5600 6.5 31 70 154240.7600 13.5 54 107
154240.1700 2.2 13 40 154240.3700 4.2 22 55 154240.5700 6.8 34 74 154240.7700 14 54 107
154240.1800 2.3 13 40 154240.3800 4.3 24 58 154240.5800 7 34 74 154240.7800 14.5 56 111
154240.1900 2.4 14 43 154240.3900 4.4 24 58 154240.5900 7.5 34 74 154240.7900 15 56 111
154240.2000 2.5 14 43 154240.4000 4.5 24 58 154240.6000 7.8 37 79 154240.8000 15.5 58 115
152705 Body drill GÜHRING
HSS
α: 118º

P M K N

554, HSS, diameters 2.4 and larger damped, works standard, with pointing.
Application
For double-ended use in thin materials, such as in auto body work.
Tolerance: d1:h8
Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
152705.0100 2 7.5 38 152705.0750 3.3 11.2 49 152705.1150 4.3 15.5 58 152705.1550 5.3 17 62
152705.0150 2.1 7.5 38 152705.0800 3.4 12.5 52 152705.1200 4.5 15.5 58 152705.1750 6 19 66
152705.0350 2.5 9.5 43 152705.0850 3.5 12.5 52 152705.1250 4.6 15.5 58 152705.1850 6.5 21.2 70
152705.0400 2.6 9.5 43 152705.0900 3.6 12.5 52 152705.1300 4.8 17 62 152705.1900 6.8 23.6 74
152705.0450 2.7 10.6 46 152705.0950 3.7 12.5 52 152705.1350 4.9 17 62 152705.1950 7 23.6 74
152705.0600 3 10.6 46 152705.1000 4 14 55 152705.1400 5 17 62
152705.0650 3.1 11.2 49 152705.1050 4.1 14 55 152705.1450 5.1 17 62
152705.0700 3.2 11.2 49 152705.1100 4.2 14 55 152705.1500 5.2 17 62
