Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
132600 Square-shoulder cutter 90° WALTER Xtra.tec
F4042

Straight shank with Weldon flat and internal cooling.
Application
The WALTER Xtra.tec shoulder milling system with its Xtra extra-positive geometry is outstandingly
suited to general machining of steel and cast iron. Through the combination of the highly positive,
soft-cutting geometries with the Tigertec types, you receive a product that is hard to match for
high cutting speeds and long life. This system makes it very easy in many cases to achieve produc-
tivity improvements.
Indexable inserts: 132620
Spare parts: 138040
Order ID Dc d1 X1 Lc X2 Z ap
mm mm mm mm mm mm
132600.0100 10 16 31 8 80 1 8
132600.0200 12 16 31 8 80 1 8
132600.0300 16 16 41 8 90 2 8
132600.0400 20 20 39 8 90 3 8
132600.0500 25 25 43 8 100 4 8
132600.0600 32 32 49 8 110 5 8
132750 Square-shoulder cutter 90° WALTER Xtra.tec
F4042

Straight shank with Weldon flat and internal cooling.
Application
The Xtra.tec shoulder milling system with its Xtra extra-positive geometry is outstandingly suited
to general machining of steel and cast iron. Through the combination of the highly positive, soft-
cutting geometries with the Tigertec types, you receive a product that is hard to match for high
cutting speeds and long life. This system makes it very easy in many cases to achieve productivity
improvements.
Indexable inserts: 132820
Spare parts: 138040
Order ID Dc d1 X1 Lc X2 Z ap
mm mm mm mm mm mm
132750.0100 25 25 43 11.7 100 3 11.7

132800 Square-shoulder cutter 90° WALTER Xtra.tec
F4042
Cylindrical bore with cross drive DIN 138.
Indexable inserts: 132820
Spare parts: 138040
Order ID Dc d1 X1 Lc Z ap
mm mm mm mm mm
132800.0100 40 16 40 11.7 5 11.7
132800.0200 50 22 40 11.7 6 11.7
132800.0300 63 22 40 11.7 7 11.7
