Milling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
134120 Indexable insert COROMANT
CoroMill 390
P M K N S

For 134100, 234200
Designs
• E: Precision-ground, for light cuts
• M: Direct-pressed, for rough machining
Geometries
• P (steel), M (stainless), K (cast iron), N (non-ferrous metals), S (superalloys), H (hard)
• F (finish machining), M (moderate machining), R (rough machining)
Types
• 1025: for steel, stainless steel, non-ferrous metals, superalloys and hardened steel.
• 530: Cermet; for steel, stainless steel, non-ferrous metals, and hardened steel.
• 4230: all-round grade, for steel and cast iron
• 2030: for steel, stainless steel and superalloys
• 4240: tough, for steel, stainless steel and cast iron.
• 2040: for steel, stainless steel and superalloys
• 3040: for steel, cast iron and hardened steel.
• H13A: uncoated; for aluminium and superalloys.
Order ID Code Type B I iW r s ap
mm mm mm mm mm mm
134120.0200 R390-11 T3 08E-PL 530 1.5 11 6.8 0.8 3.59 10
134120.0300 R390-11 T3 08M-PL 1025 1.2 11 6.8 0.8 3.59 10
134120.0450 R390-11 T3 08M-PL 4230 1.2 11 6.8 0.8 3.59 10
134120.0500 R390-11 T3 08E-ML 2030 1.5 11 6.8 0.8 3.59 10
134120.0650 R390-11 T3 08M-PM 4230 1.2 11 6.8 0.8 3.59 10
134120.0750 R390-11 T3 08M-PM 4240 1.2 11 6.8 0.8 3.59 10
134120.0100 R390-11 T3 04M-PM 1025 0.9 11 6.8 0.4 3.59 10
134120.0800 R390-11 T3 08M-MM 2030 1.2 11 6.8 0.8 3.59 10
134120.0900 R390-11 T3 08M-MM 2040 1.2 11 6.8 0.8 3.59 10
134120.1000 R390-11 T3 08M-KM 3040 1.2 11 6.8 0.8 3.59 10
134120.1100 R390-11 T3 08E-KL H13A 1.2 11 6.8 0.8 3.59 10
134120.1200 R390-17 04 08M-PH 4240 1.5 15.7 9.6 0.8 4.76 16
134120.1300 R390-17 04 08M-PL 1030 1.5 15.7 9.6 0.8 4.76 16
134120.1400 R390-17 04 31E-NL H13A 1.5 15.7 9.6 3.1 4.76 15.7
139050 Corner cutter 90° FUTURO

High-precision corner cutter 90° nickel-plated with internal cooling and high stock removal rates
even in less powerful machining centres.
Indexable inserts: 139060
Spare parts: 139300
Package content: Screwdriver not included.
Order ID D H d Z ap Turning plate
mm mm mm mm
139050.0100 25 32 25 3 8 SDKT
139050.0200 32 40 32 4 8 SDKT
139050.0300 40 40 16 5 8 SDKT Ø25..32
139050.0400 50 40 22 6 8 SDKT
139050.0500 63 40 22 7 8 SDKT
139050.0600 80 50 27 9 8 SDKT
