Milling with changeable milling head Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
130635 Milling head ISCAR Multi-Master

VHM TiN Z
4-6
P M K S H
Ti-Ni 44-56
HRC
Roughing
• IC908: tough fine-grain type. For heat-resistant alloys, austenitic stainless steel, hard alloys and
carbon steel up to 60 HRC, with medium to high cutting speed.
Particularly resistant to notch wear and formation of built-up edges.
Order ID D d1 L ap Ts Z
mm mm mm mm
130635.0100 8 7.6 10 5 T05 4
130635.0200 10 9.6 13 7 T06 4
130635.0300 12 11.5 16.5 9 T08 4
130635.0400 16 15.2 20.5 12 T10 5
130635.0500 20 18.3 25.5 15 T12 6
130640 Milling head 45° ISCAR Multi-Master
VHM TiAIN Z
4

P M K S H
Ti-Ni 44-56
HRC
Slot and shoulder cutting
• IC908: tough fine-grain type. For heat-resistant alloys, austenitic stainless steel, hard alloys and
carbon steel up to 60 HRC, with medium to high cutting speed.
Particularly resistant to notch wear and formation of built-up edges.
Order ID D R d1 L ap Ts
mm mm mm mm mm
130640.0100 8 0 7.6 10 5 T05
130640.0200 10 0 9.6 13 7 T06
130640.0300 10 0.5 9.6 13 7 T06
130640.0400 10 1 9.6 13 7 T06
130640.0500 12 0 11.5 16.5 9 T08
130640.0600 12 0.5 11.5 16.5 9 T08
130640.0700 12 1 11.5 16.5 9 T08
130640.0800 16 0 15.2 20.5 12 T10
130640.0900 16 0.5 15.2 20.5 12 T10
130640.1000 16 1 15.2 20.5 12 T10
130650 Milling head ISCAR Multi-Master
VHM TiAIN Z
4

P M K S H
Ti-Ni 44-56
HRC
Roughing and finishing, uneven tooth pitch
• IC908: tough fine-grain type. For heat-resistant alloys, austenitic stainless steel, hard alloys and
carbon steel up to 60 HRC, with medium to high cutting speed.
Particularly resistant to notch wear and formation of built-up edges.
Order ID D d1 L ap b Ts
mm mm mm mm mm
130650.0100 8 7.7 10 5 0.3x45 T05
130650.0200 10 9.6 13 7 0.4x45 T06
130650.0300 12 11.7 16.5 9 0.5x45 T08
130650.0400 16 15.3 20.5 12 0.6x45 T10
130650.0500 20 18.45 25.5 15 0.6x45 T12
