Profile cutter, misc. cutters Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 24220 Solid carbide engraver‘‘s cutter 60°

VHM

P K N S
≤ 850 Ti

7017, fine-grain carbide, finish-ground, point 0.1 mm (+/-0.02) .
Application
Especially well suited to fine engraving in steel.
Tolerance d2: h6
Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm
124220.0100 2 5 25 124220.0400 5 10 50
124220.0200 3 8 38 124220.0500 6 18 57
124220.0300 4 12 50 124220.0600 8 14 63
1 24240 Solid carbide engraver‘‘s cutter, fat
VHM

P M K N S
≤ 600 ≤ 900 Ti-Ni
≤ 900
7020, flat, fine-grain carbide, rough-ground.
Tolerance d2: h6
Order ID d1 l2 l1 Order ID d1 l2 l1
mm mm mm mm mm mm
124240.0100 2 3 25 124240.0500 6 8 57
124240.0200 3 4 38 124240.0600 8 10 63
124240.0300 4 5 50 124240.0700 10 12 72
124240.0400 5 6 50
