Profile cutter, misc. cutters Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
124112 Solid carbide deburrer 90° FUTURO

VHM TiAIN Z
4-6
P M K N S
≤ 900 Cu Ti-Ni
AI≥4%Si ≤ 900
Type N, TiALN, HA, work standard, long, without tip.
Application
For deburring and chamfering workpiece edges, also for contour work. For general-porpose use
up to 46 HRC.
Order ID d1 l2 d2 d3 l1 Angle Z
mm mm mm mm mm
124112.0100 1 0.35 3 0.3 40 90° 4
124112.0200 2 0.7 3 0.6 40 90° 4
124112.0300 3 1 3 1 50 90° 5
124112.0400 4 1.25 4 1.5 50 90° 6
124112.0500 6 2 6 2 50 90° 6
124113 Solid carbide deburrer 60° FUTURO
VHM TiAIN Z
4-6

P M K N S
≤ 900 Cu Ti-Ni
AI≥4%Si ≤ 900
Type N, TiALN, HA, from 6mm on HB, DIN 6527 long.
Application
For deburring and chamfering workpiece edges, also for contour work. General-purpose use up
to 46HRc.
Order ID d1 l2 d2 l1 Angle Z Shank
mm mm mm mm
124113.0100 4 2 4 54 60° 4 HA
124113.0200 6 3 6 57 60° 4 HB
124113.0300 8 4 8 63 60° 5 HB
124113.0400 10 5 10 72 60° 6 HB
124113.0500 12 6 12 83 60° 6 HB
124113.0600 16 8 16 92 60° 6 HB
124113.0700 20 10 20 104 60° 6 HB
124190 Solid carbide deburrer 90° FUTURO
VHM TiAIN Z
4
P M K N
≤ 850 ≤ 900 AI
≥ 4% Si
Type N, TiALN, HA, from 8mm on HB.
Application
For deburring and chamfering workpiece edges, also for contour work.
Order ID d1 l2 d2 l1 Angle Shank
mm mm mm mm
124190.0100 4 2 4 54 90 ° HA
124190.0200 6 3 6 57 90 ° HB
124190.0300 8 4 8 63 90 ° HB
124190.0400 10 5 10 72 90 ° HB
124190.0500 12 6 12 83 90 ° HB

548 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
